Home > Products > Stud Roll Forming Machine > Metal Stud Roll Forming Machine, Hydraulic Cutting Drywall Edge Bead Roll Forming Machine
Metal Stud Roll Forming Machine, Hydraulic Cutting Drywall Edge Bead Roll Forming Machine
- 0 Metric Ton / Metric Tons per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
U Angle Roll Forming Machine, Metal Stud Metal Roll Forming Machine, 6000x800x1200mm
-
6500 x 800 x1200mm Stud Forming Machine, Automatic Edge Trim Roll Forming Machines
-
Stud Keel Steel Roll Forming Machine, Portable Hydraulic Metal Forming Machine
-
Main Channel Stud Roll Forming Machine, 5.5KW Automatic Metal Forming Machine
-
Hydraulic Cutting Stud Roll Forming Machine, L Angle Metal Roll Forming Machinery
-
Furring Channel Steel Roll Forming Machine, Automatic Metal Stud Roll Forming Machine
Product Details
| Brand Name | Friendship | Place of Origin | China | |
Product Description
Certification:ISO
Metal Stud Roll Forming Machine, Hydraulic Cutting Drywall Edge Bead Roll Forming Machine
1: Coil width: depend on customer profile
2: working speed: 12m—15m/min (not contain cutting)
3: roll station: 14stations
4: material of roller: Gcr15 steel, polished and coated with chrome HRC58-62℃
5:material of main shaft:45﹟forge steel?? diameter roller: Ф56mm
6: main power: 5.5kw????
7: forming thickness: 0.5mm—1.5mm mild steel
8: Transmission: by single line 1.0 inch Chains
9: size of machine: about 6000 x 800 x1200 (L x W x H)
10: weight: about 4000Kgs
11: color: blue and yellow (it is also can changed depend on customer request)
12:? Cutting:
(1)?? machine adopt hydraulic cutting
(2)?? Cutting after forming: Cut the sheet after roll forming to required length
(3)?? Cutting motion: The main machine automatically stops and the cutting will take place. After the cutting, the main machine will automatically start.
(4)?? Material of blade: CR12with heat treatment
(5)?? Length measuring: Automatic length measuring
(6)?? Tolerance of length: 3m 1.5mm
Contact Us
- Friendship Machinery Co.,Ltd
- Contact nameMr Wang Chat Now
- Phone86-0510-82234202
- AddressROOM 722 ,MACHINERY BUILDING 151# Fuxing Road, Ankang, Shaanxi
