Half Round Gutter Forming Machine, Hydraulic Cutting Steel Gutter Forming Machine

Half Round Gutter Forming Machine, Hydraulic Cutting Steel Gutter Forming Machine

1.? 125mm or 150mm, two profiles

2: working speed: 0m—12m/min (not contain cutting)

3: roll station: 17-19 stations (base on final design)

4: material of roller: 45＃forge steel, polished and coated with chrome

5:material of main shaft:45﹟forge steel?? diameter roller: Ф65mm

6: main power: 5.5kw????

7: forming thickness: 0.5-0.6mm painted or galvanized steel.

8: Transmission: by Chains 1.2inch single line

9: size of machine: about 7000 x 1000 x 1200 (L x W x H)

10: weight: about 6000Kgs

11: color: blue and yellow (also can change depend on customer request)

12:? Cutting:

(1) Machine adopt hydraulic cutting

(2)?? Cutting after forming: Cut the sheet after roll forming to required length

(3)?? Cutting motion: The main machine automatically stops and the cutting will take place. After the cutting, the main machine will automatically start.

(4)?? Material of blade: CR12 with heat treatment

(5)?? Length measuring: Automatic length measuring

(6)?? Tolerance of length: 3m 1.5mm

B.? de-coiler

Dimensions: 1700mm*1000mm*800mm

Width of feeding: 500mm

Capability: 3 Ton

Bound of expand &fight: 480mm—550mm

Mode of expand &fight: inner expand &fight by manual

Way of feeding: manual
