Continuous casting machine / R6M 3S CCM / Billet CCM with Hydraulic Billet cutting machine

Steel billet casting machine radius

6m

Strand quantity

3 strands

Ladle support type

Ladle turret,Ladle car

Tundish carriage

Semi-portal, cross sliding function

Casting method

Metering nozzle, open casting

Secondary cooling

Water cooling , 1 adjusting circuit

Withdrawal straightening machine

Totally 5 roller, progressive straightening

Roll table

Chain group centralized drive

Dummy bar

Rigid, with self-adapting dummy bar head

Billet cutting

Hydraulic cutting machine

Billet conveying

Group centralized live roller table

Cooling bank type

Simple cooling bed

Nominal capacity

30T

Tap-to-tap cycle?

60min

Furnace quantity?

2set

Working days

330 days/year

Average number of daily furnace

24/day

Production capacity

300,000t/year

Casting sectional area(mm)

100×100

125×125

150×150

Casting speed(m/min)

3.0

2.7

2.5

NO.

Billet

size

Casting speed

hourly output

(tons)

Daily output

24hour

(tons)???

Annual output(330days)

(tons)

1

100×100

3.0m/min

12.01

288.

95123

2

125×125

2.7m/min

16.89

405

133,767

3

150×150

2.5m/min

21.72

521

172,061

Steel grade

Casting grade(m/min)

Effective deformation rate(ε)
