6 Layer Halogen Free OSP surface treatment SMT PCB Board Manufacturing
- T/T L/C D/P D/A
- 7 days
You May Like
-
0.5 - 6oz 6 Layers Controlled Impedance PCB Boards for Communication Equipment
-
White Solder Mask Lead Free Hasl Single Layer Alumina 1.6mm PCB For LED Street Light
-
FR408 White Solder Mask Enig Surface 6 Layers HDI PCB for Game Machines
-
FR4 tg170 6 Layer HASL / Lead free HASL Immersion Gold HDI Multilayer PCB with Red Mask
-
10 Layers FR4 tg170 1.6mm Immersion Gold OSP HDI PCB for Industrial Control Computer
-
Prototype 3 Layer FR-1 HASL lead free PCB Fabrication and Assembly
Product Details
| Brand Name | zhongda | Place of Origin | China | |
Product Description
Certification:UL E354810,SGS
6 Layer Halogen Free OSP surface treatment SMT PCB Board Manufacturing
Description
1.?Single-sided, ?double?side?&?multi-layer?PCB?with?competitive?price, ?good?quality?and?excellent?service.?
2.?FR-1, CEM-1, ?CEM-3, FR-4, ?FR-4?High?TG, ?Aluminum?base?material.?
3.?HAL, ?HAL?lead?free, ?Immersion?Gold/?Silver/Tin, ?OSP?surface?treatment.?
4.?Printed?Circuit?Boards?are?94V0?compliant, ?and?adhere?to?IPC610?Class?2?international?PCB?standard.?
5.?Quantities?range?from?prototype?to?medium?batch?production.?
6.100%?E-Test
Application
Products are applied to a wide range of High-tech industries such as: LED, telecommunication, computer application, lighting, game machine, industrial control, power, automobile and high-end consumer electronics, ect. By unremitting work and effort to the marketing, products exports to American, Canada, Europe counties, Africa and other Asia-pacific countries
Advantage
1.PCB?factory?directly?
2.PCB?high?quality?
3.PCB?good?price?
4.PCB?quick?time?
5.PCB?certification(ISO/UL/RoHS)...
Specification
|
SERIAL? |
ITEM |
TECHNICAL?DATA? |
|
1 |
Layers |
2－16(layers) |
|
2 |
Max?Board?Size |
18\"?x?24\" |
|
3 |
Max?Board?Thickness |
6mm? |
|
4 |
Min?Line?Width |
4mil |
|
5 |
Min?Line?Space |
4mil |
|
6 |
??Min?Hole?Size |
12mil |
|
7 |
??PTH?Wall?Thickness |
1mil |
|
8 |
??PTH?dia?tolerance |
±3mil |
|
9 |
?NPTH?hole?dia?tolerance |
±2mil |
|
10 |
??Hole?Position?Deviation |
±2mil |
|
11 |
??Outline?Tolerance? |
±6mil |
|
12 |
S/M?Pitch |
3mil |
|
13 |
??Insulation?Resistance |
1E+12Ω(Normal) |
|
14 |
?Thermal?Shock? |
??288?℃(3x10Sec)? |
|
15 |
Warp?and?Twist |
≤0.7% |
|
16 |
Electric?Strength |
＞1.3KV/mm |
|
17 |
Peel?Strength |
1.4N/mm |
|
18 |
Solder?Mask?Abrasion |
≥6H? |
|
19 |
Flammability |
94V-0 |
|
20 |
Electrical?test |
10V?-250V |
|
Material? |
Surface?Finish? |
|
CEM-1? |
OSP? |
|
FR-4? |
HASL? |
|
FR-4?High?TG? |
HASL?lead?free? |
|
Aluminum?PCB |
Immersion/Chemical?Gold? |
Contact Us
