IP67 Protection level Baclight i Industrial Keyboard with Touchpad and numeric keypad

General Specification

SPC410AM stainless steel keyboard is suitable for a number of harsh and public access environments such as self-service kiosks, public access kiosks and industrial process control.

??? A wide range of models are available with combinations of full-QWERTY and numeric keypad. Other hardware options include tracker balls and pointing devices. PIN pad only and trackball only modules are available.

?Applications Field:

n????????? Public access applications including self-service kiosks

n????????? Unattended payment solutions and information kiosks

n????????? Industrial control systems including process control

n????????? Military Industry?

Electric Characteristics

-????????? ?Power Supply: DC5V+10%

-????????? Communication interface: USB

-????????? Power consumption: <0.5W (dynamic), <0.2W(static)

Touchpad

-????????? ?Work area dimension: 60x44mm

-????????? sealed and ruggedized tough touchpad.

-????????? More than Lifetime 10 million strokes

-????????? Mutual Capacitance sensing

-????????? Tracking speed: Maximum 1,016 m/sec

-????????? Power supply voltage: 5 VDC ±0.25V

Mechanical characteristics

-????????? Total keys: 96

-????????? Size: 410*146mm

-????????? Weight: 2kg

-????????? Key life span: > 3,000,000 times

-????????? Key pressure: 2-3N

-????????? Key travel: 0.45mm

-????????? Key and panel material: high stainless steel

-????????? Protection level: IP67

-????????? Key graphics: laser engraved lettering and strong painting

Environment Adaptability:

? Protection level: IP67

? Operation temperature range: -25°C~+65°C

? Relative humidity range: 30%~90% RH(normal environment)

? Storage temperature range: -40°C~+80°C

? Relative storage humidity range: 20-95%(non-condensing)

? Air pressure: 60-106kPa

Certification

CE,FCC,RoHS

Dimensions

? SPC410AM

Front plate: W410 x D146(mm)

? Overall: W415 x D151x24.5H

Gross Weight

2.3KG
