ZFWY-40 Horizontal Rebar Bend Test Machines with Touch Screen, Electronic Bend Tester

Brand Name	Bairoe		Place of Origin	China
Model Number	ZFWY-40/ZFWY-50

Delivery Time:A month
Certification:ISO 9001, CE

ZFWY-40 Horizontal Rebar Bend Test Machines with Touch Screen, Electronic Bend Tester

The ZFWY series of rebar bend and re-bend testing machine is our latest development for bending tests on ribbed rebar, construction rebar, capable of bending and re-bending tests on ribbed rebar to inspect its bending performance and its re-bending performance after aging. This product is mainly applied in quality control department for iron forging and construction, as well as bending performance inspections on construction raw material and steel welds. It is a common instrument to perform material bending performance tests and researches in iron industries, science research departments, quality control departments, construction, railway, transport, higher education and etc. This product features a horizontal frame, which is efficient, beautiful and takes a small footprint. The rotation angle is set digitally. The touch-screen interface enables easy and convenient operations. This product is integrated with a two-way hydraulic cylinder. The two-way ball screws move the bending roller. The rollers go back and forth simultaneously, making it easier to adjust the distance of cold bending. The rollers are installed on the piston to perform bend and re-bend tests on specimen. This product complies with the standards and requirements of GB 1400.2-2007, YB/T 5126-2003, GB/T 232-1999 and etc. This product features a complete set of functionalities, easy operations, an efficient structure, safe and reliable performances and etc.

Features:

Operating: digital buttons, touch-screen interactions, performing operations through only some simple clicks. Effortless: requiring only one operator, who clicks the buttons to perform tests. Safe: specimen bending directly into sealed test table, safe to operate. Dust-proof: unique dust resistant unit protects ball screw from oxide coating. Small footprint saves space for testing.

Technical Specifications:

Model	ZFWY-40	ZFWY-50

Specimen range

6～40 mm

6～50 mm

Main cylinder travel

400mm

Max rotation

180°

Reverse rotation

20°

Roller span adjustment style

Manual

Flexural center diameter type

18,24,28,30,32,36,40,42,48,54,56,60,64,66,70,72,75,80,84,88,96,98,100,112,108,

120,126,128,132,140,144,150,154,160,175,180,196,200,224,250,256,280,288,300,

320,400,450mm and etc. 47 types in all. Customized

Power supply

3kW/AC380V/50Hz

4kW/AC380V/50Hz

Frame dimensions

1250×860×1200mm3

1400×880×1200mm3

Weight

Approx. 1200 kg

Approx. 1500 kg
