300L Automatic VME Vacuum Toothpaste Emulsifying Machinery With German Nash- Elmo

Brand Name	Melding		Place of Origin	China

Delivery Time:3-10 Days
Certification:CE
300L automatic VME? vacuum toothpaste emulsifying machinery with German Nash- elmo

Use:

The?300L ?vacuum toothpaste homogenizing emulsifiers machines/toothpaste whole production line?are suitable for production of ointment and cream products in cosmetic and pharmaceutical plants.The emulsifying effect is more prominent for materials of high base viscosity and high solid content.

VME vacuum emulsifier is professionally designed according to the ointment manufacturing processof cosmetics and ointments etc. products through introducing advanced technology from abroad. The machine unit is composed of pre-treating boiler,vacuum emulsifying and blending boiler, vacuum pump, hydraulic system, dumping system, electric control system and work platform etc. The machine unit is featured by simple operation, stable performance, good homogenizing performance, high production efficiency, convenient cleaning, reasonable structure, small land area and high automatic degree etc.

Advantage:

This Emulsion series machine mixer adopt two speed on one shaft. Hydraulic System,homogenizer speed:0—3500 r/min (speed controlled),stirring speed:0—63 r/min(speed controlled).Vacuum suck material. all the process under vacuum state.CIP system is provided, all contact material parts adopt SUS316L,lnner jacket polishing reach 300EMSH (sanitation grade)vacuum Dump adopt German Nash- elmo (former Siemens)technology.Meet GMP requirement.
?

Toothpaste making machine from A to Z designed by lianhe cosmetics factory for our singapore customers.The whole production includes the machine such as?

? ? ? ? ?1.Water Treatment with ultrafilter and EDI ? ? ? ? ?2.toothpaste vacuum emulsifier? ? ? ? ? ?3. storage Tank ? ? ? ? ?4.inner heating tube filling&sealing machine ? ? ? ? ?5.Conveyor Belt ? ? ? ? ?6.5L lab vacuum emulsifier ? ? ? ? ?7.Laboratory High shear homogenizer

Model	Effective Capacity	Emulsify	Agitator	Outside Dimension	The merit rate
KW	r/min	KW	r/min	Length	Width	Height	Maxh	Electric Heating	Steam Heating
VMB-20	20	0.75	0-3000	0.37	0-40	1800	1600	1850	2700	9	9
VMB-50	50	2.2	0-3000	0.37	0-40	2700	2000	2015	2700	25	5
VMB-100	100	3	0-3000	1.5	0-40	2920	2120	2200	3000	27	9
VMB-150?	150	3	0-3000	1.5	0-40	3110
