C Section Roll Forming Machine with Gearbox Drive for Making Steel C Section TW-C300

Brand Name	TECHWELL		Place of Origin	China
Model Number	TW-C300

Delivery Time:55-65 working days
Certification:CE

C Section Roll Forming Machine with Gearbox Drive for Making Steel C Section TW-C300

?

A). Work Flowing of C Section Roll Forming Machine:

Decoiler --- Fedding & Leveling --- Roll Forming --- Punching --- Cut-to-length --- Run out table

Applications:

C purlin, c shaped purlin, c channel, lip channel, c section, c profile, c shape, steel c purlin, c purlin steel structure

B). Main Specifications:

Material: GI, Carbon steel Material thickness: 1.5-3.0mm Machine diameter: about 11500x1500x1300mm ( LXWXH ) Weight of machine: about 10 Ton Decoiler: Manual or hydraulic decoiler ( customer can choose ) Weight capacity of decoiler: 5 Ton Forming station: 14 Principle axis: 75mm diameter Forming speed: 0-15m/min Drive type: 1.5\' chain transmission Roller material: GCr15 steel, quenched? and heated process Main power: 15KW Hydraulic power: 11KW Punching: hydraulic punching Electrical Control: PLC Frequency Control System with touch screen PLC: PANASONIC Brand Encoder: OMRON Brand Transducer: PANASONIC Brand

C). ?Main Components:

Decoiler ---------------------------------------------- 1 Unit Feeding & Leveling -------------------------------- 1 Unit Main roll forming machine ------------------------ 1 Unit Hydraulic punching device ----------------------- 1 Unit Hydraulic cutting device -------------------------- 1 Unit Hydraulic Station ----------------------------------- 1 Unit PLC computer control ----------------------------- 1 Unit Output table ----------------------------------------- 1 Unit

Competitive Advantage:

High Quality Reasonable Price Good after Service 1 Year Warranty More Than 10 Years Experience
