Product Details
| Brand Name | GUOHUA | Place of Origin | China | |
| Model Number | ZL15F |
Product Description
Detailed Product Description
Weifang mini loaderFront end loader with snow blower
CE mini front loader
Rated bucket capacity:0.7 m3
Xinchai A498BT1 (EUR
Model ZL15F Wheel Loader
Use: Wheel loader ZL15F is mainly used in road construction, urban construction, environment cleaning, coal yard, sand and stone quarry, small and medium civil engineering, railway station, wharf, freight yards, warehouse, etc. to shovel and load or transfer loosing soil, sand and stone, coal cinder, trash and other loosing materials. Compact wheel loader can be used together with 3-5 tons tractor and truck to load and unload materials and also can be used to carry out the works such as bulldozing, shoveling and digging, dragging, stacking, lifting and traction, etc.
Performance
| Rated Load | 1500 kg |
| Total Weight | 3400 kg |
| Rated Bucket Capacity | 0.7 m3 |
| Max. Tractive Force | 30KN |
| Max. Breakout Force | ≥ 32 KN |
| Max. Gradeability | 38° |
| Dumping Height | 2800 mm |
| Dumping Reach | 1000 mm |
| Raising Time | ≤ 5.0s |
| Total Cycle Time | ≤ 9.5 s |
| Overall Dimensions (L x W x H) | 5060*1690*2630 mm |
| Min. Turning Radius | 3200 mm |
| Model | XINCHAI A498BT1 (EURO III) |
| Type | Four-cylinder, Inline, Water-cooled, Four-stroke Engine |
| Rated Power | 36.8 kw |
| Rated Speed | 2400 rpm |
| Min. Fuel Consumption Ratio | ≤ 230 g/kw·h |
| Hydraulic Torque Converter | ZL265 Integrated Torque Converter |
| Gear Shift | 1 Forward, 1 Reverse, 1 High Speed, 1 Low Speed |
| Max. Speed | 25 km/h |
| Model of Axle | 50 Axle |
| Wheel Tread | 1430 mm |
| Wheel Base | 2170 mm |
| Mode | 4-way Drive |
| System Working Pressure | 16 Pa |
| Fuel Tank Capacity | 86 L |
| Service Brake | Single-line, Hydraulic, Expansion-shoe Brake on 4 Wheels |
| Parking Brake | Hand Flexible Shaft Controlled Disc Brake |
| Type Specification | 12-16.5 |
| Front Tyre Pressure | 0.40 Mpa |
| Rear Tyre Pressure | 0.35 Mpa |
