45W SMD3014 LED Panel Lighting With 4000 Lumens 600*600*11.5mm

45W SMD3014 LED?Panel?Lighting With 4000 Lumens 600*600*11.5mm

Product Specifications:

LED Panel Lightings/Flat LED Panel Light 45W
Item No.:RB-PL-6060-B
Input Voltage: AC 85~265V/ 50-60HZ
LED Power:45W
LED Quantity: 624PCS SMD 3014
Power Factor:>0.95;Power Efficiency:>0.88
LED Luminous Flux Warm White,Nature White, Pure White
LED Panel light Viewing Angle: 120 degree
Color Temperature Warm White 3000K~3500K
Nature White 4000K~4500K,Pure White 5500K~6500K
Luminous Flux:4000LM(6000K)
Color Rendering Index : Ra≥80
Working Temperature: –40oC~50oC
IP Grade: IP54
Body Size: 600*600*11.5mm
Material: Aluminium /SPCC/PMMA
Working Life-span: 50000 H
Certificate CE & RoHS &TUV


Features:

1. Energy-efficient, environment-friendly
2. No glare, no noise, no UV
3. Ultra slim and fashionable design
4. Maintenance free, easy installation
5. No maintenance for the life of unit, apart from cleaning
6. Remote-control dimming available
7. Solid-state, high shock/vibration resistant
8. No fluorescent flickering
9. No danger of broken glass
10.Long lifetime, 50, 000+hrs(5+years)



Applications:

1. Commercial and exhibition locations
2. Hotel, conference room
3. Factory, office, house
4. Airport, metro station
5. School, hospital and other public places
6. Place that require energy-efficiency and high color rendering index


?

Competitive Advantage:

1.50% energy saving same watts compare with CFL traditional lights .
2.No glare , no UV , no pollution . Friendly to environment , healthful for man
3.low luminous decay . 3% luminous decay After 2000hrs
4. Wide range voltage 85-265VAC
5. No need in cooling . It is the good integrated heating dissipation and aesthetic design .
6. Dimmable can be option . Color changing, to be red, green , blue , yellow etc. or luminance to be more brighter just as you like .
7. Saving energy saving the earth and saving your money

LED Panel Light Installation

1.Please note the power wiring of positive and negative when installation power wiring (positive with word)
2.Connect into the panel lamp terminals power wire needs to tighten with the screw
3.To avoid danger, pls cut off power supply before connecting wiring.4.Lock the screw, pls not use


Embedded installation of led panel light???

1.Taken the ceiling and LED panel light turn 45 degrees, and put it above the ceiling , pls do not force squeezing or through the ceiling
2.please placed panel lamp handled with care, ensure the products shine with the best effect
3.Choose embedded installation LED panel lamp, first consideration that wether the panel light and the size of the ceiling corresponds

Suspension installation of led panel light???

1.Pls put a soft mat on the floor before Installing corner fixing parts , lest scratches or damaged panel
2.please placed panel lamp handled with care, ensure the products shine with the best effect
3.Lock the screw, pls not use greatly forcibly, lest crush the panel lamp
1.The first open four φ5mm holes on the ceiling
2.Make the glue plug put into open good holes
3.Screw through fixed cap, locked in plug hole
