Home > Products > Mini Hepa Filter > Polypropylene, High Air Flow Mini Hepa Filter For Air Conditioning System With Gi Frame
Polypropylene, High Air Flow Mini Hepa Filter For Air Conditioning System With Gi Frame
USD $10 - $20
1 (Min.Order)
- 0 per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
High Efficiency 2 Grids Pleated Mini Hepa Filter With Anodized And Extruded Aluminum Frame
-
Glass Fiber Pleated Mini Hepa Filter With Hot-Melt Beads Separator For Clean Room
-
Aluminum Frame, 125% Rated Air Flow, h13 / h14 Mini Pleated Hepa Filter For Clean Room
-
Low Initial Resistance, Glass Fiber Pleated Mini Hepa Filter for Industrial HVAC System
-
Plastic Frame Pleated Mini Hepa Filter - EN 1822 V Bank Filter WIth High Air Flow Rates
-
Hot-Melt Beads Separator v Bank Filter, 5000 m3/Hr Mini Hepa Filter With High Efficiency
Product Details
| Brand Name | Jowell | Place of Origin | China | |
| Model Number | ZW-FV/HV |
Product Description
Certification:CE
Polypropylene, High Air Flow Mini Hepa Filter For Air Conditioning System With Gi Frame
Media:?Polypropylene??or?glass?fibre?paper Separator:Hot-melt?beads Frame:?GI;Plastic Efficiency?range?from?F9?,H10,H11,H13(EN?1822)? Initial?resistance:?110?Pa Recommended?final?pressure?drop?:?600Pa Humidity?resistance:?100% Max?Temperature:?80?℃ Sealant:?Polyurethane?rubber?PU DIN?53438?Flammability:?F1 UL?900?Standard?:??Class?2 Max.air?flow?rate:??125%?of?rated?air?flow Gasket:?one?piece?half?round?continuous?gasket Available?in?Box?or?Single?flange?type.Applications:
The ZW- FV/HV are used in high efficiency final filtration in air conditioning systems, where very high airflow required.
Specifications:
|
Size(WxHxD)mm |
Filter?Efficiency |
Media?area?m3 |
Airflow/pressure?drop?m3/h/Pa |
|
305x610x292 |
E10 |
14 |
2000/160 |
|
595x595x292 |
E10 |
21 |
4000/160 |
|
610x610x292 |
E10 |
35 |
5000/160 |
|
305x610x292 |
E12 |
16 |
1500/110 |
|
595x595x292 |
E12 |
33 |
3400/110 |
|
610x610x292 |
E12 |
40 |
4000/110 |
|
289x595x292 |
H13 |
16 |
1300/110 |
|
595x595x292 |
H13 |
38 |
3200/110 |
|
610x610x292 |
H13 |
40 |
4000/110 |
Other?sizes?is?available!
Competitive?Advantage:
Ensure?a?long?operation?reliability?and?high?dust?holding?capacity High?air?flow?rates,?up?to?5000?m3/hr Low?initial?resistance. Tested?in?accordance?with?EN?1822 Low?energy?consumpation.Contact Us
