800mm Dia, 300mm Knife Length Slicing Machine / Knife - Ring Flaker BX468
- T/T L/C D/P D/A
- 7 days
You May Like
-
BX4612 Knife - Ring Flaker / Slicing Machine With 1200mm Dia.of Knife Ring, 935 rpm
-
BX466 High Speed 1960 rpm Rotation of Impeller Knife - Ring Flaker / Slicing Machine
-
BX466 Double Drum Wheel Knife-Ring Flaker / Slicing Machine With 225 mm Knife Length
-
BX466 225mm, 50 rpm Knife - Ring Flaker With Vibration Feeder, Magnetic Sorting Device
-
BX466 0.4 - 0.7 mm Flakes Thickness Knife-Ring Flaker For Producing Particleboard ISO9000
-
BX466 Double Drum Wheel Vibrating Knife - Ring Flaker / Slicing Machine With 600mm Dia
Product Details
| Brand Name | Xu Brand | Place of Origin | China | |
| Model Number | BX468 |
Product Description
Certification:ISO9000,CE
800mm Dia, 300mm Knife Length Slicing Machine / Knife - Ring Flaker BX468?
This equipment consists of vibration feeder , magnetic sorting device, separator of heavy objects, knife ring, impeller and machine base .
The main motor of impeller drives impeller by V-belt with a high speed. And the direction of rotation should to comply with arrowhead of base. Face to the machine door , the impeller should be running in anticlockwise direction . The knife ring is driven by reducing motor through chains and chains wheel in low velocity .the direction of rotation is different from impeller .
Applications:
Double drum wheel flaker is specially designed for using wood chips, milled veneer as the raw materials, shaving the materials into a certainty thickness of flake which be used to produce particleboard.
Specifications:
|
Technical data/Model |
BX468 |
|
Dia.of knife ring?????????? mm |
800 |
|
Quality of knives????????? piece |
28 |
|
Knife length?????????????? mm |
300 |
|
Rotation of knife-ring????? r.p.m |
50 |
|
Rotation of impeller??????? rpm |
1450 |
|
Flakes thickness??????????? mm |
0.4-0.7 |
|
Main motor power????????? kw???? ? |
132 |
|
Productivity???????????? kg/h |
1500-3000 |
|
Weight?????????????? kg |
5800 |
|
Dimension?????????????? mm |
3130×2512×2380 |
