1oz Copper 1.6mm FR4, HAL Custom Prototype Single Sided PCB For TV, Mobile
- T/T L/C D/P D/A
- 7 days
You May Like
-
Green 1.6mm Routing, Punching OSP Gold Finger Single Sided Pcb With Electrical Test
-
Electrical Test 1.6mm NPTH Prototype Printing Single Sided Pcb Board With Gold Finger
-
PTH, OSP Custom Punching Copper Thickness Single Sided PCB With Immersion Gold
-
HAL / ENIG Routing, Punching OSP, HAL Prototype Double Sided PCB With Gold Finger
-
0.2 - 3.2mm FR4 HAL / ENIG PTH, NPTH, OSP Double Sided PCB With Gold Plating
-
0.5 - 3oz Copper FR4 Prototype PTH, NPTH Double Sided Circuit Board For Mp4, Led
Product Details
| Brand Name | Winnal | Place of Origin | China | |
| Model Number | CE, ROHS, UL |
Product Description
1oz?Copper?1.6mm?FR4,?HAL?Custom?Prototype?Single?Sided?PCB?For?TV,?Mobile
Description:
|
Layer |
1 |
|
Material |
FR4 |
|
Thickness |
1.6mm |
|
Surface?finishing |
HAL |
|
Copper |
1oz |
|
Test |
Electrical?Test |
Specifications:
|
Product?Technical?Parameter |
|||
|
Basic?technology |
Parameter |
||
|
Single/Double?sided |
Multilayer |
||
|
Number?of?Layers |
1-2 |
4~16 |
|
|
Copper?Thickness |
0.25~3.0OZ |
0.5~3.0OZ |
|
|
Base?Board?Thickness |
0.2~3.2mm |
0.6~3.2mm |
|
|
Incombustibility |
94V-0 |
94V-0 |
|
|
Peelable?resistance |
12.3N/cm |
12.3N/cm |
|
|
Twist? |
≤0.5% |
≤0.5% |
|
|
Insulation?resistance |
≥1011Ω |
≥1011Ω |
|
|
Test?voltage |
10-300V |
10-300V |
|
|
Finished?board?area |
560×970mm |
560×970mm |
|
|
Min.?Line?Width?and?Spacing |
0.1/0.1mm |
0.1/0.1mm |
|
|
Copper?thickness?in?hole |
≥25.0um |
≥25.0um |
|
|
Mini.?pad?diameter |
Inner?layer |
0.05mm |
|
|
Out?layer |
0.076mm |
0.076mm |
|
|
Mini.?Hole?Diameter |
0.25mm |
0.20mm |
|
|
Hole?tolerance |
PTH |
±0.076mm |
±0.076mm |
|
NPTH |
±0.05mm |
±0.05mm |
|
|
Hole?location?tolerance |
±0.076mm |
±0.05mm |
|
|
profile?tolerance |
Routing |
±0.1mm |
±0.1mm |
|
Punching |
±0.13mm |
±0.13mm |
|
|
Solder?mask?bridge?ability |
≥0.1mm |
≥0.075mm |
|
|
Solder?mask?rigidity |
6H |
6H |
|
|
Solderable?test |
245℃?????5?second |
245℃?????5?second |
|
