Home > Products > Drilling Rig Mud Pumps > BW-320 30 Kw 8.0 Mpa Single-acting triplex plunger drilling rig mud pumps
BW-320 30 Kw 8.0 Mpa Single-acting triplex plunger drilling rig mud pumps
Negotiable
/ Meter
1 Meter(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
BW-160/10 drilling rig mud pumps applied to geological and water conservancy
-
Flange Joint type horizontal directional drilling tools , pup joints , tube unions
-
Directional drilling tools Non-dig Drill Pipe with different Thread form S135 Grade
-
Directional drilling tools Flange Joint , pilot drill bits,pilot broads
-
2 3/8 Size IEU thickening type directional drilling tools Non-dig Drill Pipe Rod
-
10T,15T,20T,30T,40T,50Tdirectional drilling tools sub between swilvel and dill pipe
Product Details
| Brand Name | SINOCOREDRILL | Place of Origin | China | |
Product Description
Certification:CE
BW-320 30 Kw 8.0 Mpa Single-acting?triplex?plunger drilling rig mud pumps
|
BW-320?MUD?PUMP |
||
|
Type |
Single-acting?triplex?plunger |
|
|
Stroke |
110mm |
|
|
Bore |
80mm |
60mm |
|
Pump?speed?(s.p.m) |
214, 153, 109, 78 |
214, 153, 109, 78 |
|
Output?volume?(l.p.m) |
320, 230, 165, 118 |
180, 130, 92, 66 |
|
Discharge?pressure?(Mpa) |
4.0, 5.0, 6.0, 8.0 |
6.0, 8.0, 9.0, 10.0 |
|
Input?power?(Kw) |
30 |
|
|
Suction?pipe?dia?(mm) |
75 |
|
|
Discharge?pip?dia?(mm) |
50 |
|
|
Drilling?hole?depth?(m) |
Diamond?core?drilling?<?3000 |
|
|
Conventroxal?core?drilling?<?2000 |
||
|
Weight?(Kg) |
650?(without?power) |
|
|
1000?(with?motor) |
||
|
Overall?dimensions?(mm) |
1280*855*750 |
