WP15-20 electric pallet truck, 2000kg with 600mm load centre with AC motor

FOB Price

Negotiable / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Shintool		Place of Origin	China
Model Number	WP15-20

Delivery Time:30 days after receive the payment
Certification:CE

WP15-20 electric pallet truck, 2000kg with 600mm load centre with AC motor???????????????

The second generation products have started batch production.

The new products line are mostly equipped with EPS and AC motor!

We are keeping our leading position in China on products quality and design!

2.5T Full electric pallet truck, With Electric Power Steering (EPS) system, With AC motor, Color is optional.

Specifications:

Model				WP15-20
characteristics		capacity	kg	2000
	load centre	mm	600
	operator type		walkie
	Electric power steering(EPS)		standard equipped
dimensions	h	lifting height	mm	110
H1	ground clearance+fork thickness	mm	85
B1	standard fork width	mm	540/685
L1	fork length	mm	1150/1200
S	fork thickness	mm	55
E	fork width	mm	185
L	overall length	mm	1830
L2	rear length	mm	680
B	overall width	mm	720
Wa	minimum turning radius	mm	1655/1705
	aisle width (800*1200mm pallet): horizonal/vertical	mm	2255/2355
	aisle width (1000*1200mm pallet): horizonal/vertical	mm	2405/2455
performance		maximum traveling speed	laden	km/h	4.5
unladen	km/h	4.5
	maximum lifting speed	laden	m/s	0.056
unladen	m/s	0.06
