112W Modular LED Street Light Fixtures 100 - 122lm/w AC 90 - 305V

Model No.

KT-SL-112W

Replacement

400W High Pressure Sodium Lamp

LED Light Source

Bridgelux LED

LED Quantity

112 pcs

LED Working Current

400 mA

Lamp Rated Total Power

160W

Power Efficiency

> 90%

LED Luminous Efficiency

100-122lm/w

Lamp Rated Total Luminous Flux

> 13, 600lm

Lamp Rated Luminous Efficiency

85lm/w

lllumination and Effective Area

lllumination

Effective Area

Height 6M

83 lux

24X6M

Height 8M

47 lux

34X8M

Height 10M

30 lux

40X10M

Height 12M

20 lux

50X12M

Color Rendering Index(CRI)

Ra>75

Color Temperature(Color Temperture)

Cool white: 5000-6300K?
Pure white: 3700-5000K?
Warm white: 2700-3300K

Beam Angle

Horizontal Axis:60°
Vertical Axis:130°

Light Distribution Curve(Beam Pattern)

Asymmetric (Bat Wing) / Rectangular Beam

Input Voltage

AC 90-305V

Frequency Range

47-63Hz

Power Factor(PF)

≥ 0.95

Total Harmonic Distortion(THD)

< 15%

Storage Temperature

－40℃--+80℃

Working Environment

－40℃--+50℃; 10%-95%RH

Junction Temperature(Tj)

60℃±10%(ta=25℃)

Light Body and Lampshade Material

Aluminum Alloy

Working Lifetime

> 50, 000hrs

IP Rating

IP66

Net Weight

16.5kg

Gross Weight

18.1kg

Product Dimension (mm)

993(L)×380(W)×125(H)mm

Package Size (mm)

1067(L)×442(W)×170(H)mm
