Descrition:?

The?cantilever?climbing?formwork?PJ200?&?PJ240?are?widely?used?in?concrete?pouring?of?piers,

?high-rise?buildings,?and?a?variety?of?other?structures.??

The?concrete?lateral?pressure?is?entirely?supported?by?anchor?system?and?the?wall-through?tie-rods.?

Therefore,?additional?reinforcement?is?not?needed.?The?construction?is?easy,?rapid?and?economical,?

and?the?surface?of?the?concrete?is?slick.

The?biggest?advantage?of?PJ?series?is?light?in?weight?and?convenient?in?use.?The?operation?platform?

width?of?PJ200?and?PJ240?is?200cm?and?240cm?respectively.

The?Characteristics

The?formwork?unit?can?move?backwards?up?to?600mm.
The?formwork?is?flexible?to?adjust?from?all?directions.
The?inclination?can?be?adjusted?by?pull-push?prop?and?is?up?to?18°.
Reasonable?structure?and?light?weight.
High?level?of?universality?and?standardization?for?connection?components.
?

?Structure?Sketch

The?Concrete?Pouring?Process

The?first?pouring
Before?pouring,?fix?the?anchor?system?on?the?plywood?by?M30?position?bolt?or?construction?bolt.?

Reinforce?the?formwork?by?wall-?through?tie?rods.

The?second?pouring(the?first?lift)
Climbing?brackets?are?used?in?the?second?pouring.?Fix?the?anchor?shoe?in?the?bowl-climbing?cone

?by?tensile?bolt,?hang?the?bracket?on?the?anchor?shoe,?and?then?insert?the?safe?pin.

The?third?pouring(the?second?lift)
Fix?suspended?platform?under?the?climbing?bracket.?Workers?can?remove?the?tensile?bolt,?anchor?

shoe?and?bowl-climbing?cone?for?reusing,?and?then?fill?the?holes?left?by?bowl-climbing?cone.?

This?pouring?process?is?the?standard?pouring;?the?later?lifting?process?is?the?same,?till?the?concrete?pouring?is?finished.
