AC100V - 240V 120 Beam Angle 10W Restaurant Square Cob LED Down Light
Negotiable
/ Meter
1 Meter(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
Frosted PC, High Luminous 4\'\' 5W Cob LED Down Light With 50000 Hours Life Span
-
High Efficiency AC100V - 240V 3000K, 4000K, 5000K E27 4W Cob LED Bulb
-
Low Heat 250 - 315LM 5W RA70 Energy-saving E26 Cob LED Bulb For Home
-
High Efficiency Glass, Aluminum, RA70 15W E27, 250 - 315LM Cob LED Bulb
-
5W AC / DC 12V Low Voltage Clear Glass Die Cast Aluminum, ABS MR16 Cob LED Bulb
-
Energy Saving 250 - 315LM E14 3W Multi-chip Cob LED Bulb With 240 Beam Angle
Product Details
| Brand Name | JD | Place of Origin | China | |
| Model Number | JD- FS1606PTSS |
Product Description
Certification:CCC, CE, RoHS
AC100V - 240V 120° Beam Angle 10W Restaurant Square Cob LED Down Light
10W?COB?LED?DOWN?LIGHT?SQUARE?6?INCHES
1.Diverse options: 3000K, 4000K, 5000K for warm white, true white and cold white color temperature, clear or frosted ?lens for choice
1. Integrated low power multi-chip COB surface light-source, with independent IP protection, high quality Epistar chip, each chip is 0.08W, with low current load (26mA) and efficient circuit design
2. Low heat production, perfect heat dissapation, within 70° for junction temperature, the luminous decline is no more than 5% within10, 000 hours, ensuring a long life span
3. High Luminous efficiency (> 80LM/W for light engine), radiation angle is 120o, ?no need of secondary optical design ??
4. Japanese IC power supply, specially designed based on our light board, no electrolytic capacitor, well matched the long life design of our LED, with high power factor (>90%) and transfering efficiency (>85) ?
5. No glare, no double image, no color shifting
6. Simple structual and installation: PC lighting fixture without extra cooling structure, buit-in driver, light, convenient and cost saving for transportation and installation
7.Diverse options: 3000K, 4000K, 5000K for warm white, true white and cold white color temperature, clear or frosted ?lens for choice
8. CCC, CE, RoHS certificates, 3 years\' gurantee from the date of delivery (1 to 1 free repacement for any quality defective)
Applications:
Hotel, Restaurant, Office, Shopping Mall, Super Market, Residence, Hospital, Coffee Bar, Club, Staircase, Entrance, Toilet
2. Low heat production, perfect heat dissapation, within 70° for junction temperature, the luminous decline is no more than 5% within10, 000 hours, ensuring a long life span
3. High Luminous efficiency (> 80LM/W for light engine), radiation angle is 120o, ?no need of secondary optical design ??
4. Japanese IC power supply, specially designed based on our light board, no electrolytic capacitor, well matched the long life design of our LED, with high power factor (>90%) and transfering efficiency (>85) ?
5. No glare, no double image, no color shifting
6. Simple structual and installation: PC lighting fixture without extra cooling structure, buit-in driver, light, convenient and cost saving for transportation and installation
7. Integrated low power multi-chip COB surface light-source, with independent IP protection, high quality Epistar chip, each chip is 0.08W, with low current load (26mA) and efficient circuit design
8. CCC, CE, RoHS certificates, 3 years\' gurantee from the date of delivery (1 to 1 free repacement for any quality defective)
Applications:
Hotel, Restaurant, Office, Shopping Mall, Super Market, Residence, Hospital, Coffee Bar, Club, Staircase, Entrance, Toilet
Specifications:
|
Model: |
JD-FS1606PTSS |
|
|
Input?Voltage: |
AC100V-240V, ?50/60Hz |
|
|
Power: |
10W |
|
|
Lumens: |
800-880LM?(LED?Engine) |
|
|
Beam?Angle: |
120° |
|
|
Installation?Hole: |
150mm*?150mm |
|
|
Index: |
RA70 |
|
|
Fixture?Material: |
PC, ?Aluminum |
|
|
Lens: |
Clear?or?Frosted?PC |
|
|
Temperature?Color: |
3000K, ?4000K, ?5000K |
|
|
Certificate: |
CCC, ?CE, ?RoHS |
|
|
IP: |
40 |
|
|
Life?Span |
50000?Hours |
|
|
10W?Square?Down?Light?(6?inch) |
Dimension: |
φ170mm*H95mm |
