Home > Products > Directional Yagi Antenna > 450MHZ CDMA Wireless Directional Yagi Antenna 12 dBi With 6 Element, N Female Connector
450MHZ CDMA Wireless Directional Yagi Antenna 12 dBi With 6 Element, N Female Connector
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Outdoor 2.4GHZ 18DBI High Gain Directional Yagi Wireless Antenna With 18 Element
-
GSM 900 Mobile telecommunication Directional Yagi Antenna 806 - 960 MHz 18 dBi
-
GSM1800 / PHS Directional Yagi Antenna 1710- 1880 MHz, 15 dBi, SMA Female Connector
-
Wireless Transmission Multiband Log-periodic Antenna 800- 2500MHZ With N Female Connector
-
High Gain Ceiling Mount Multiband Omni-directional Antennas 3 dBi, N Female, 165 * 95
-
Waterproof Omni Directional Ceiling Mount GSM / CDMA / PCS / 3G / WLAN Multiband Antenna
Product Details
| Brand Name | Runshine | Place of Origin | China | |
| Model Number | RSY-433-12 |
Product Description
Certification:ROSH
450MHZ CDMA Wireless Directional Yagi Antenna 12 dBi With 6 Element, N Female Connector
Feature:
● High Gain
● Aluminum Alloy frame
● Full day for working
● Optimized dimension
● Optional installation H or V
Application:
● 450MHZ CDMA System
● 450MHZ Wireless Access system
● Village to Village project?
Specification
|
Model?NO |
RSY-450-470-12 |
|
Electric?Spec |
|
|
Frequency?rang-MHz |
450-470 |
|
Bandwidth?-MHz |
20 |
|
Gain?-dBi |
12 |
|
element |
6 |
|
beam?width?-° |
H:42????V:38 |
|
F/B?Ratio-dB |
≥16 |
|
VSWR |
≤1.5 |
|
Input?Impedance-Ω |
50 |
|
Polarization |
Horizontal?or?Vertical |
|
Max?power?-W |
100 |
|
Lightning?protection |
DC?ground |
|
Connector?model |
N?female?or?others |
|
Mechanical?Specification |
|
|
Size?-mm |
870*340*80 |
|
Cable?length-m |
0.3 |
|
Antenna?weight-kg |
0.52 |
|
Working?Temperature?-°c |
-40～60 |
|
Rated?Wind?Velocity-m/s |
60 |
|
Clamp |
U |
|
Pole?diameter?-mm |
Φ40～Φ50 |
