Indoor Signal CDMA800 / GSM900 / 3G / WLAN Multiband Antenna Panel 7 / 10 dBi
- T/T L/C D/P D/A
- 7 days
You May Like
-
Directional High Gain WCDMA / PCS / 3G Flat Panel Antenna 14 dBi 1710 - 2170 MHz
-
2.4GHZ Long Distance Transmission Directional Grid Parabolic High Gain 3G Antenna
-
High Gain WCDMA / PCS / 3G Sector Base Station Antennas Directional Panel 18 DBi
-
Waterproof Anti-interference Omni Directional Ceiling Mount Multiband 2.4 GHZ Wifi Antenna
-
White DC Ground Mural Panel Directional 2.4 GHZ Wifi Antenna Wall Mount 14 dBi
-
Directional 2.4 GHZ Wifi Base Station Panel Antenna 2400 - 2500 MHz 18 DBi N Female
Product Details
| Brand Name | Runshine | Place of Origin | China | |
| Model Number | RSW-800-2500-10 |
Product Description
Certification:ROSH
Indoor Signal CDMA800 / GSM900 / 3G / WLAN ?Multiband Antenna Panel ?7 / 10 dBi
Feature:
● Good appearance
● Durable, corrosion resistance
● Full day for working ,waterproof
● Optimized dimension
● High Gain, Lower VSWR, Strongly Anti-interference
Application:
● Indoor signal coverage
● CDMA800/GSM900/3G/WLAN system
● Wireless transmission?
Specification
|
Model?NO |
RSW-800-2500-10 |
|
Electric?Spec |
|
|
Frequency?rang-MHz |
806～960/1710～2500 |
|
Bandwidth?-MHz |
154/790 |
|
Gain?-dBi |
7/10 |
|
beam?width?-° |
H:70/60??V:55/45 |
|
VSWR |
≤1.5 |
|
Input?Impedance-Ω |
50 |
|
Polarization |
Vertical |
|
Max?power?-W |
50 |
|
Lightning?protection |
DC?ground |
|
Connector?model |
N?Female |
|
Mechanical?Specification |
|
|
Size?-mm |
210*180*45 |
|
Antenna?weight-kg |
0.57 |
|
Working?Temperature?-°c |
-40～60 |
|
Rated?Wind?Velocity-m/s |
60 |
|
Radome?color |
white |
|
Mounting?way |
mount?on?the?wall?or?hold?in?the?pole |
