3 axis Turning machine PC Based CNC programming Controller with Built - in PCL

CNC?function

Maximum?controllable?axes:?36?feed?axes?and?one?spindle?axis

Maximum?coordinate?axes:?6

Minimum?resolution:?1?μm?????????

Automatic?control?of?acceleration?and?deceleration
?(straight?line/?S?curve)

Returning?to?reference?point

Setting?coordinates

Graphic?simulation?of?machining?process?and?real-time?tracking

?????????????nMDI?function?

M,?S,?and?T?functions

Graphic?static?simulation?of?machining?process?
and?real-time?tracking

fixed?circular?turning??

CNC?programming

Minimum?programming?unit:?0.001?mm

Maximum?programming?size:?99999.999

Maximum?programming?lines:?5000000?????

Metric/imperial?programming

Absolute/incremental?programming

Macro?instruction?programming

Calling?subroutine

Setting?workpiece?coordinates

Diameter/radius?programming

Automatic?control?of?chamfering?
(round?angle,?right?angle)

Interpolation?function

Line?interpolation?for?a?maximum?of?six?axes

Circular?interpolation????????????????????

Thread?cutting

Tool?compensation?function

Tool?length?compensation

Tool?radius?compensation

Operation

8.4-inch?TFT?color?display

Anti-static?electricity?program?and?machine?operation?panel

Standard?PC?keyboard?interface

Hand-held?units?(optional)

Graphic?display?and?dynamic?real-time?simulation

Network?communication?(optional)

Feed?axis?function

Unrestrained?axis?rotation?function

Maximum?speed:?43000?mm/min

Feed?override:?0%?to?150%????????

Rapid?movement?override:?0%?to?100%

Various?modes?of?returning?to?the?reference?point:
?single?direction?and?bi-direction

Spindle?function

Spindle?speed:?specified?by?PLC?programming
?(Maximum?speed:?60000?rpm)

Spindle?speed?override:?0%?to?150%

Displaying?spindle?speed?and?override

Variation?ratio?and?variation?ratio?level:?
specified?by?PLC?programming

Auxiliary?function

?n?nSpindle?CW/CCW?

??nAutomatic?tool?change???

Cooling?on/off

PCL?function

Built-in?PLC???

Standard?PLC?sample

Displaying?PLC?status
