Home > Products > Cob Led Module > DC24V 830mA 20W High Power Aluminum Alloy Flat Cob Led Module, 80 - 90 LM / W
DC24V 830mA 20W High Power Aluminum Alloy Flat Cob Led Module, 80 - 90 LM / W
Negotiable
/ Unit
1 Unit(Min.Order)
- 0 Unit / Units per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
12W Round Cob Led Module 24V With 50000h Longevity For Down Light
-
77 * 3mm 960 - 1020 LM 12W Round Cob Led Lighting Source 24V For Down Lighting
-
20 * 20 * 3 MM Low Voltage DC 24V 410mA 10W Cob Led Module For Bulb
-
Aluminum Alloy Shell, 1360 - 1445 LM 17W Round Cob High Power Led Module DC 24V
-
Environment Friendly High Lumens DC18V 850 - 950 LM 10W Cob Led Modules
-
60 * 3mm 600 - 675 LM DC 24V 200mA 7.5W Cob Led Round Modules
Product Details
| Brand Name | JD | Place of Origin | China | |
| Model Number | JD-R026080-24V |
Product Description
Certification:CCC, CE, RoHS
DC24V 830mA 20W High Power Aluminum Alloy Flat Cob Led Module, 80 - 90 LM / W
Flat COB LED Module
1. LED chip is fixed on aluminum layer of aluminum base PCB. The heat from chip can be spread out through aluminum layer rapidly.
2. Low lighting decay, decay less than 3% after 1000 hours.
3. Equable and soft irradiancy, no glaring and eye Protection.
4. Good reliability, no dead bulb and no motting.
5. LED full lighting module can be combined into different LED lights easily.
6. Highly Color-rendering index and lighting effect. Safty, Environment friendly. ? ?
Applications:
Round?full?lighting?module?is?widely?used?for?LED?bulb, ?LED?cup?, LED?spot?light, ?LED?down?light?and?so?on.
Specifications:
|
Category |
Name |
Data |
|
Electrical?data? |
Voltage/Current?Voltage |
DC15-17V/300mA |
|
Voltage |
DC24V830mA |
|
|
Power?Consumption |
20W |
|
|
Luminance?Efficiency |
80-90LM/W |
|
|
Luminance?data |
Luminous?flux |
1700-1900LM |
|
Color?temperature(CCT)? |
3200K±200K??(warm?white)??????????? 5500K±200K??(natural?white)???????? 4500K±300K??(?cold?white) 6000k±300K?(day?white) |
|
|
Color?rendering?index(CRI)? |
Ra>80? |
|
|
Shell?material |
Aluminum?alloy |
|
|
Integrated?data |
Working?temperature Ambient??temperature |
-20°C~60°C? |
|
Longevity |
≥50000h |
|
|
Dimensions? |
L39XW22XH4mm |
|
|
Luminous?Surface?Dimension |
18x11mm |
Competitive Advantage:
LED cob lamp surface is fixed on aluminum layer of aluminum base PCB. The heat from chip can be spread out through aluminum layer rapidly.
1. High Lumens:
?The lumens of our products can reach up to 75-85Lumen per watt for warm white color and 90-100lumen per watt for white color. It is the first-rate in China even in the World.
2. Equable Lighting:
? ? The lighting surface is a whole part and avoid the glaring one by one lamp so it can protect humen eyes from glaring.
3. Better Heat Dissipation:
? ? ?The chips are fixed on the aluminum base directly. Due the better dissipation of the aluminum, the heat can be spread out from it quickly so this can lengthen the lifespan of LED.
Competitive Advantage:
LED cob lamp surface is fixed on aluminum layer of aluminum base PCB. The heat from chip can be spread out through aluminum layer rapidly.
1. High Lumens:The lumens of our products can reach up to 75-85Lumen per watt for warm white color and 90-100lumen per watt for white color. It is the first-rate in China even in the World.
2. Equable Lighting:The lighting surface is a whole part and avoid the glaring one by one lamp so it can protect humen eyes from glaring.
3. Better Heat Dissipation:The chips are fixed on the aluminum base directly. Due the better dissipation of the aluminum, the heat can be spread out from it quickly so this can lengthen the lifespan of LED.
Description:
Flat COB LED Module
1. LED chip is fixed on aluminum layer of aluminum base PCB. The heat from chip can be spread out through aluminum layer rapidly.2. Low light
