High Power AC 240V 7 Inch 10W Recessed Cob Led Downlight Fixtures

FOB Price

Negotiable / Meter

1 Meter(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	JD		Place of Origin	China
Model Number	JD-FR1606PTSA

Product Description

Delivery Time:3-5working days after received deposit.
Certification:CCC, CE, RoHS

High Power AC 240V 7 Inch 10W Recessed Cob Led Downlight Fixtures

10W RECESSED COB LED DOWN LIGHT 7 INCHES

1. Integrated low power multi-chip COB surface light-source, with independent IP protection, high quality Epistar chip, each chip is 0.08W, with low current load (26mA) and efficient circuit design

2. Low heat production, perfect heat dissapation, within 70° for junction temperature, the luminous decline is no more than 5% within10, 000 hours, ensuring a long life span

3. High Luminous efficiency (> 80LM/W for light engine), radiation angle is 120o, ?no need of secondary optical design ??

4. Japanese IC power supply, specially designed based on our light board, no electrolytic capacitor, well matched the long life design of our LED, with high power factor (>90%) and transfering efficiency (>85) ?

5. No glare, no double image, no color shifting

6. Simple structual and installation: PC lighting fixture without extra cooling structure, buit-in driver, light, convenient and cost saving for transportation and installation

7.Diverse options: 3000K, 4000K, 5000K for warm white, true white and cold white color temperature, clear or frosted ?lens for choice

8. CCC, CE, RoHS certificates, 3 years\' gurantee from the date of delivery (1 to 1 free repacement for any quality defective)

Applications:

Hotel, Restaurant, Office, Shopping Mall, Super Market, Residence, Hospital, Coffee Bar, Club, Staircase, Entrance, Toilet

Specifications:

	Model:	JD-FR1606PTSA
Input?Voltage:	AC100V-240V, ?50/60Hz
Power:	10W
Lumens:	800-880LM?(LED?Engine)
Beam?Angle:	120°
Installation?Hole:	φ170mm
Index:	RA70
Fixture?Material:	PC, ?Aluminum
Lens:	Clear?or?Frosted?PC
Temperature?Color:	3000K, ?4000K, ?5000K
Certificate:	CCC, ?CE, ?RoHS
IP:	40
Life?Span	50000?Hours
10W?Recessed?Down?Light?(7?inches)	Dimension:	φ190mm*H96mm
	Key?Components:	Unique?Light?Board?with?IP? protection, ?Japanese? IC?Power

Dimension?(mm):

Detailed?Images:

Competitive Advantage:

1. Novel design: COB LED down light , Unique circuit design, using high-performance constant-current drive , thereby achieving a highly efficient energy-saving purposes. The surface shell with special aluminum alloy, have good heat dissipation, beautiful appearance , installation and replacement, safe and convenient usage. ?

2. Efficient and energy-saving: With high-performance constant-current power supply, conversion efficiency is greater than 90%, 60% energy saving, life span is up to 30000-50000 hours. ?

3. Stable Performance: Apply to AC85-265V 47-63Hz wide voltage, broad frequency input, AC conversed to DC, reducing LED decay, starting fast, no flicker, hard to damage product under frequent turning on and off. ?

4.Environment friendly: Using new LED light source, no mercury, lead and other hazardous substance, no pollution to environment. It will not produce ultraviolet and infrared and other rays, causing very low heat, no attraction to mosquitoes, very clean and healthy for indoor usage. The product is recyclab
