Gardner Denver PZ-7 Mud Pump Module Assembly

Heat-treatedand internally hardened for high durability; available in various materials tomeet a wide range of applications; standard one-and/or-two-piece configuration,with designs available for pressure of 5000psi(35.1Mpa),  7500psi(52.7Mpa), and 10000psi(70.3Mpa);discharge connections available on each side; suction connections on each sideor front center.

Material is 35CrMoA or 40CrMoNn alloy forged steel.To get better fiber texture, we use electric stove for second forging, ordeoridation treatment. It is forged from three directions and the forging ratiois not less than 4.0:1.0. It can not have crack, impurity, looseness,overburns, etc. And weld is not allowed. It should be confirming to thestipulation of JB/TQ252-81, and should be checked by gradeⅢ Afterquenching the rough module will be rough processed, then the hull hardness isHB285-330.

Mechanicalproperty: σb ≥850MPa, σs≥670MPa, δ≥5%,ψ≥30%.

Thetwo1:6(1:12) taper hole rolling treatments are checked by ring gage. Itscontact area has continuous distribution on the circumference. The contact areais not less than 75% .The line of intersection of all cylindrical surface ofthe hull are facetted obtuse angle by hand or grinding wheel ,forming acircumference R≥8.Test pressure is 49Mpa, keep pressure 1 hour, pressure cannot be reduced. Finished products have crack detection report.

DetailedProduct Description
Triplex Fluid End Modules:
Our high strength forged triplex fluid end modules, are made from 4130 or 4135metal and heat treated to a hardness for long wear. The clean exterior finishreflects the superior inside quality.
We furnish all associated items with the modules:
Valve and cylinder head plugs
Valve cylinder head threaded rings
Valve cylinder head locks
Studs and nuts
Duplex Fluid Ends:
Our principal also maufactuers duplex fluid end modules to API standards
