Uv led curing printing machine

Xin Tian Run Multifunctional LED Flatbed Printer can print on almost all flat materials, such as metal, glass, acrylic, crystal, plastic, ceramic, leather, wood, paper, etc. The printing theory is digital inkjet printing, direct print on object without plate-making. The process of printing is very simple and easy. Using UV inks with high color fastness direct printing to all flat materials. Flatbed UV printer is widely used in many fields.

Advantages of Xin Tian Run Multifunctional LED Flatbed Printer:

1. LED curing lamp, long working life, can be used for more then 10000 hours.

2. LED lamp required low power less than 200W, much less than the UV curing lamps.

3. Epson/Mutoh DX5 printheads, high printing quality with max resolution in 2880dpi.

4. With professional printing software and computer operating.

5. UV inks with high color fastness, waterproof, 3-5 years durable outdoor.

6. No need pre-coating for many materials, eg Acrylic, PVC, ABS, Wood, KT sheet, etc

Model A1  XTR 7880  LED Flatbed Printer

  Product description:

- Print size: super A1 Format, max printing range 0.61m * 2.5m

- Print head: MicroPiezo TFP 1440 Nozzles, Epson Variable-Sized Droplet Technology

- Print color: 4/5/6/7 colors  "(C,M,Y,K)x2" or "CMYK+4White" or "CMYK+LC+LM+2W"

- Max thickness of flat printing : 15cm

- Printing weight: Precision nondestructive weight 100kg

- Max printing precision: 2880 * 1440 dpi

- Ink System: UV ink, LED lamp curing, dry instantly

- Printing speed:

   (A1 Format) Around 5.0min (720 * 360dpi/ quality mode)

                        Around 7.2min (720 * 360 dpi/ speed mode)

                        Around 9.9min (720 * 720 dpi/ quality mode)

                        Around 14.3 min (1440 * 720dpi/ photo mode)

                        Around 26.9min ( 2880 * 1440dpi/ excellent photo mode)

- Power requirement: 110-220V  50-60Hz  750W

- Interface: USB 2.0/1.1 interface, 100 Base T Ethernet interface

- Operation system: Window 95,98,NT,2000,XP,2003/MAC/linux

- Working environment: Temperature 10-35C, Humidity 20-80RH

- Net weight/ Gross weight : 650KG/800KG

- Dimensions: 3.5m * 1.5m * 1.3m
