Product Details
| Brand Name | Zhongzhong | Place of Origin | China | |
| Model Number | N/A |
Product Description
Certification:EN10228 Class D
1.5 / 2.0 / 2.5 / 3.0MW Wind Power Spindle Forging, Forged Steel Shaft 42CrMo4, 34CrNiMo6
Description:
Forged steel shaft-wind power spindle forging is widely used for large scale wind power equipment enterprise. For example: Jingfeng Windpower, Vestas, Siemens and so on. The products conform to Standard of EN10228 Class D
The manufacturing equipment is 30MN hydraulic press, the forging ratio >4.5, the technical condition is in accordance with the standard of EN10228 Class D
The product can be provided as per your drawing or specified requirements.
?? ?
Smelting Process:EF+LF + VD
The process as? follow? :Ingot →heat → forging → Heat treatment (Normalizing+ tempering) → Inspection →rough machining→UT →2nd Heat treatment →finishing machining →Inspection
???
Applications:? Forged steel shaft-wind power spindle forging is widely used for large scale wind power equipment.
Specifications:
|
Description |
Forged?steel?shaft-wind?power?spindle?forging |
|
material |
Alloy?steel?(42CrMo4,?34CrNiMo6?etc.) |
|
Material?standard |
ASTM?or?GB/T3077-1999 |
|
Specification |
1.5MW,?2.0MW,?2.5MW,?3.0MW |
|
Weight? |
Max.?30?ton |
|
Smelting?Process: |
EF+LF?+?VD |
|
Process |
Ingot→heat?→?forging?→?Heat?treatment?(Normalizing+?tempering)?→?Inspection?→ rough?machining→UT?→2nd?Heat?treatment?→finishing?machining?→Inspection |
|
UT?standard |
ASTM?A388?or?EN10228 |
Competitive Advantage:
Quality control and management to the whole produce process, including ingot smelting, forging, heat treatment, machining and strictly final inspection prior to delivery.
Excellent product quality and service, competitive price, “in-time” delivery
