Pharmaceutical Cleanroom GMP required Dispensing booth:

Pharmaceutical Cleanroom GMP required Dispensing booth

Anlai holdsexpertise in offering a wide range of Laminar Flow Work Stations,

Such as the sampling booth or dispensing booth.

Our range isdesigned with open front containment systems with built-in scavengingarrangement. This ensures the powder aerosols away from the operator and theoperating environment protecting products and providing safe working conditionsfor personal.

Dispensingbooth Technical specifications:

Cleanliness:Class 100

Filtration step:Two

HEPA airfilter: 99.999% 0.3um

Pre-filter: 75%  5um

Velocity – 0.3-0.6m3/h

Noise level:57-65dB

Decibels Standard– (FS 209E)USA.

Power supply: 110V-220v/50-60HZ. 380V/50HZ

Material:Stainless steel or steel with power coated.

 StandardModel Technology Parameter:

GMP standardNegative Pressure dispensing Booth(LAF-2400)

External size:2400×1500×2400mm(W×D×H)

Internal size: 2320×1000×1900mm(W×D×H)

Cabinet:Entirely Stainless steel 304(T=1.5mm)

(Both inside and outside)

G1 Washable Pre-filter:3pcs

F7 Medium filter: 3pcs

Tank-style Mini-pleated HEPA filter, aluminum frame good sealant

HEPA efficiency EN1822:99.999% @0.3um 4pcs

Centrifugal fan: 2sets with big air volume and low noise

Noise:≤78dB,air velocity: 0.36-0.54m/s adjustable

PLC control system, Siemens brand

LED light, >/= 300lux

With different pressure gauge

PAO testing,equipped with industrial sockets and switch

Power supply:220 60HZ 1Phase
