Home > Products > Phase Relay > SVM-A Single-Phase Over or Under Voltage Relay
SVM-A Single-Phase Over or Under Voltage Relay
US$ 13 - 13
/ Piece
10 Pieces(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Place of Origin | China | |
| Model Number | SVM-A |
Product Description
Model: SVM-A (potentiometer adjustment)
Product Name: single-phase over voltage protection
Dimensions: 61H × 49W × 70Dmm
Installed base (optional): 8PFA
Main features:
● Overvoltage Protection: +5% of rated voltage +20%, adjustable, potentiometer adjustment.
● Undervoltage Protection: Rated voltage -5% -20% adjustable, potentiometer adjustment.
● action over voltage adjustable delay time 1 ~ 10S.
Rated Voltage: AC: 220V, 240V, 380V, 415V, 440V, 480V, 50/60HZ
Indicator: Power, the normal two light
Output contact: 1C, 5A 250VAC
Power consumption: ≤ 2W
Weight: 210g
Ambient temperature: -10 ℃ ~ +55 ℃
Relative Humidity: 45 ~ 85% RH
Wiring diagram:
Product Name: single-phase over voltage protection
Dimensions: 61H × 49W × 70Dmm
Installed base (optional): 8PFA
Main features:
● Overvoltage Protection: +5% of rated voltage +20%, adjustable, potentiometer adjustment.
● Undervoltage Protection: Rated voltage -5% -20% adjustable, potentiometer adjustment.
● action over voltage adjustable delay time 1 ~ 10S.
Rated Voltage: AC: 220V, 240V, 380V, 415V, 440V, 480V, 50/60HZ
Indicator: Power, the normal two light
Output contact: 1C, 5A 250VAC
Power consumption: ≤ 2W
Weight: 210g
Ambient temperature: -10 ℃ ~ +55 ℃
Relative Humidity: 45 ~ 85% RH
Wiring diagram:
