Low Noise Cortex-M3 CPU 4.2’’ LCD 730mm Simple Graph Plotter For Institutions Sign

Specifications

Model	CB730	CB1300
Media?Way	M?bracket?or?Stand	Floor?Stand?
Mainboard	Cortex-M3?CPU?, ??High-speed?32?bit?processor
Control?Panel	Highlight?patterned?LCD?, friendly?operating?keypad
Driver	double?high?torsional?force?motor, ?micro-step?driver
Position	Limit?edge?system, any?origin?setting
Max?paper?feed?width	730mm	1300mm
Max?cutting?width	700mm	1270mm
Max?cutting?speed	600mm/s
Max?cutting?length	20000mm
Max?cutting?thickness	1.0mm
Cutting?force	0-600g(digital?adjustment)?
Mechanical?precision	0.05mm
Repeatable?precision	≤0.1mm/twice(On?1000*1000mm?square)
Type?of?balde	Carbide?blade
Type?of?Plot?pen	All?types?diameter?11.?4mm?plot?pen
Protocol	Compatible?DM/PL, HP/GL
Interface	Blue?tooth/USB?Port/Serial?Port/D?Card
Power?Supply	INPUT?AC110V±10%?1.0A?60Hz, AC220V±10%?0.5A?50Hz
Power?Consumption	＜100W	＜120W
Operating?environment	Temperature:+?5±35, ?Relative?Humidity:?30%?~70%
External?size	1045300330mm	1595300415mm
Weight	16Kg	29Kg

Competitive?Advantage:

1.?Bluetooth?communication:?Can?be?connected?to?computer?within?10m?distance?, so?one?computer?

can?control several?cutters, ?and?the?cutters?will?not?interference?with?each?other.?It’s?very?convenient?

for?computer, ?mobile, ? laptop, ?notetbook?with?Bluetooth?to?control?the?cutter.?Besides, ?it?will?

overcome?the?interference?of?computer?or electrostatic.

2.?External?design?memory(short?name?D?card):?2-32M?memory, ?downloading?wire?to?connect?D?card?with?

??? computer, ?and?one?computer?can?be?configured?several?D?cards.

3.?Blue?backlight?big?LCD:?4.2’’?blue?backlight?white?character?LCD, ?128?segment?digital?display, ?more?bright, more?intuitive.

4.?Inside?carriage?increases?the?working?area:?CB730?with?cutting?width?700mm, ?CB1300?with?cutting?width?

1270mm.

5.?High-precision?roller?stick:?To?ensure?that?no?more?than?1mm?deviation?every?meters?paper?walked.

6.?High?quality?buttons:?Good?hand?feeling?, durable, ?blue?backlight

7.?laser?system:?Accurate?laser?system, ?can?do?contour?cutting.

8.?Fashion?white?color?and?Metallic?silver?appearance.

9.?Main?board?and?Driver?board?are?both?in?the?right?cover:?It?is?convenient?to?repair?and?replace, ?enhance?

??? anti-jamming?performance.

10.?Low?noise?design
