Double Mitre Saw
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | yuefeng machine | Place of Origin | China | |
| Model Number | LJZ2-500×4200(5000) |
Product Description
◎ Two heads work independently or together.
◎ Uniform speed feeding and smooth motion due to air-draulic damping cylinder.
◎ Saw blade feeding system adopts imported linear guide pair, with high accuracy and
smooth working.
◎ Automatic protecting guards result convenience and safety.
Technical Parameter
Model LJZ2-500×4200
Input voltage 380V 50Hz
Input power 4.5Kw
Air pressure 0.5~0.8MPa
Air consumption 200L/min
Motor rotation speed 2800r/min
Cutting length 360~4200mm (360~5000mm)
Cutting width 10~130mm
Cutting height 10~300mm
Cutting angle 90° 45° 67.5°
Saw feeding speed 0~3m/min
Saw blade standard φ500×4.4×φ30×Z120
Overall dimension 5500(6300)×1700×1600mm
