Portable wireless Eelctromagnetic interactive whiteboard include Computer Projector

Portable wireless Eelctromagnetic interactive whiteboard include Computer Projector

A complete set of E-Blackboard system should include the following parts:

1.Electromagnetic E-Blackboard

2.Electromagnetic Stylus

3.Personal Computer

4.Projector

5.LABWE Electromagnetic Blackboard Software

LABWE Electromagnetic Blackboard

Adopting Wireless Electromagnetic Induction technology, LABWE Electromagnetic Blackboard , is an input device providing strong interaction potential between Human and Computer, Man and Software, E-Blackboard software and other software applications. Connected the E-Blackboard to PC, the E-Blackboard screen can synchronously display content on PC screen. In the mean time, the computer can be manipulated by Electromagnetic stylus operating on the E-Blackboard screen instead of Mouse connected to the PC (enabling Left & Right Click functions). LABWE Electromagnetic Blackboard has surpassed traditional one-way operation of projection equipment system and achieved great breakthrough in terms of interaction.

Application:?? Education, business, Military

Hardware Features:

1.Accurate positioning, fast response, free from the confines of special pen or stylus

2.Module designed inductors embedded in the board frame for easy maintenance and extended-life performance?

3. Convenient intelligent pens and easy-to-reach intelligent pen tray holder

4.USB power supply, plug and play--Needless of external power supply and server

5.Durable materials--Normal ink marker writable, worry-free from naughty scratches by students and power failure

6.Harsh environment workable

Software Features:

????? 2.?Accurate nine-point calibration

????? 3.Multi-touch function supportive (in WIN7 )

????? 4.External Tool---Designed for putting application programs (Flash, .exe, etc) into our whiteboard for use

????? 5.?Smooth writing, without any breakpoint or sharp curves

????? 6.?Low CPU occupancy percentage (≤5%)

????? 7.?Abundant multimedia resources

????? 8.?Powerful PPT import and export function

????? 9.?Handwriting or/ and Drawing Recognition function--Simultaneous recognition of both handwritten word(s) in over ten different languages or hand drawn geometric shapes.

????? 10.?A variety of mathematic tools

????? 11.?Four opearating modes—Designed for meeting different demands of teachers and other user groups.

Touch Features:

Operating Principle:Electromagnetic Induction Technology

Positioning Accuracy:<2mm

Cursor Blink Rate:120 Dots/Second

Resolution:8192 × 8192

Response Time:< 5ms in continuous writing practice

Induction Size:> 2.0mm, Recommended Size:> 5.0mm (Diameter)

Single Spot Life Span:Over 60, 000, 000 times single spot touch

Working Environment:

Power Supply:USB power supply (No external power supply needed)

Operating Voltage:DC 4.6V ~ DC 5V

Power Consumption:<1W, USB 5V voltage, current < 100mA

CPU:X86-based processor, pentium III or above;

Memory:256MB RAM (512MB RAM recommended);

HDD:1GB free space;

USB:At least a spare USB interface;

Projection Equipment:Normal projector compatible.

Operating Temperature:-10 °C to 45 °C

Operating Humidity:20% to 85%

Light Test:Incandescent (220V, 100W), working distance: 350mm

Altitude:3, 000 meters or below

PC Interface:USB2.0

Working Life:5 years or above

Work Environment:Under daylight, indoor & outdoor environment.

Packing List:

Standard Accessories

LABWE Electromagnetic Blackboard:1

Writing Stylus:2

USB cable (5 Meters, Blue):1

Installation Software Disk:1

User's Manual:1

Service Card:1

Wall-mounting Parts:1

Screws (ST4 * 30mm KA):8

Plastic Gecko (6 * 29mm):8

Optional Accessories :

Mobile Stand:1set
USB Extension HUB Cable (5 Meters, Silver):1 piece
