Home > Products > plywood machinery > plywood machinery/CNC Non-chuck veneer peeling lathe
plywood machinery/CNC Non-chuck veneer peeling lathe
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
Brand Name | china | Place of Origin | China | |
plywood case
Product Description
We supply hydraulic double-chuck veneer peeling lath, hydraulic single-chuck veneer peeling lathe, mechanical single-chuck veneer peeling lathe, CNC Non-chuck veneer peeling lathe.
Some types accept OEM services.
Please contact me for more information
Thanks & Best Regards
Jimmy
Jimmy at zqmachinery point com
ZQK1813 NC spindle less veneer peeling lathe also can be called NC non-chuck veneer rotary lathe, it is automatic model, and the Chinese first-class spindle less veneer peeling lathe for quality and performances.
It is mainly used to peel the core veneer for plywood industry, most of the instructions are controlled by numerical system. The transmitting mode is ball screwing ( servo motor supply the power to gearbox, gearbox transmit the torque to ball screw, then drive the tool carriage forward and back). It uses hydraulic knife assembling system, so can reduce the labor need and increase the productivity.
The control system which used in this machine is Chinese brand; we also can equip the machine with Japanese NC system as our customer’s requirement.
Model |
ZQK1813 |
ZQK1827 |
Max. working length (mm) |
1350 |
2600 |
Max. working diameter (mm) |
280 |
280 |
Core log diameter (mm) |
40 |
40 |
Veneer thickness (mm) |
0.8-3.0 |
0.8-3.0 |
Veneer outlet speed (m/min) |
32 |
32 |
Motor power (kw) |
17.6 |
24.1 |
Net/ gross weight (kw) |
6000 |
7000 |
Packing dimension(cm) |
332 x 180 x 156 |
458.5 x 180 x 156 |
Company Profile

Weihai Zhongqiao Machinery Co., Ltd. (ZQM), is the professional plywood machinery and woodworking machinery supplier from China. Our location is Weihai City which is a beautiful coastal city--Woodworking machinery hometown in China. The main production includes woodworking machinery, multi-use woodworking machine, plywood machinery and man-made panel equipment etc. especially for multi-use woodworking machine, veneer peeling lathe, veneer clipper and edge banding machine, we are the Chinese leading manufacturer. "Science and technology constitute a primary productive force", we believe that self technical innovation is the main power for enterprise development. We have the powerful technical engineer team, who has long experience in the field of plywood and woodworking industry. For the quality control, we have more than 10 QC staffs with more than 10 years working experience to control the production quality, because we believe that the quality is the life of the enterprise, and offering the reliable production is our target for ever. Our main market includes: Russia, South-east Asia, Europe, South America, Middle east and Africa etc. The annual turnover of exporting is about 2,400,000USD. Our trademark “ZQM” has got more and more reputations from our customers. Also we welcome the dealers throughout the world to cooperating with us on the basis of equality and mutual benefit.
