Sell Microwave Power Sources (China (Mainland))

Guoguang microwave power sources are utilized in laboratories and production plants for heating, curing, drying, sintering etching and deposition in rubber, food, ceramics, semiconductor, photoelectric fibre rod, liquid, chemicals, tobacco and other applications. There are two different series of sources available: (1) 1.5 kw and 5 kw at 2450mhz. The 5 kw source has different applications. It is a very compact high stability one with a remote microprocessor controlled control unit. (2) 5 kw and 20 kw at 915mhz. For 5 kw source, high stability device is available. Wy5000.2-1c multifunction programmable microwave power source: It, utilizing guoguang 1012 ( same to yj1600 ) advanced magnetron as the microwave generator, all programmable electronic controlling circuits and a complete microwave transmitting system with a circulator, short dummy lord, electric driving tuner for auto reflecting wave control and high voltage break or arc interlock protection, makes it as a new generation of up-to-date power source for microwave plasma systems and other applications. It can operate in continuous and pulse modes with easy programmable buttone. It has enough interfaces to be connected with any other processing equipment to fulfil automatical processing control. ( all the hardware system can be located where as customer like, while a small control box with microprocessor can be placed far away with all cable connection according to user\'\' convenience. ) The features: Continuous adjustment of output power from 0.5 -- 5 kw, by hand, pre-programmable setting, and outer control signal 1 -- 10v which makes possible to be controled by computer. The eletronic regulator offers the high stability even with fluctuating of power supply voltage, loading and temperature of the magnetron. When operating the pulse modes, it permits the timebase of the pulse operation to be adjusted from 1 second to 12 hours with programmable button. Furnished with 8 input and 7 output interfaces which supplies a great possibility of processing control to diferent system and process. With the high power circulator and the eletric driving tuner, it has good performances of anti-mismatched load (even vswr over 10) and supervising the reflecting power. The filament power can be automatically for optimal long live time operating. The complete interlock system gives the power sources operating in convenience and safety. Wy1500.2-1g low ripple microwave power source: Frquency:2450 mhz +- 15 mhz Output power:150 w--1.5 kw, continuously
