Pin Aluminum Suspended Working Platform Hanging Scaffold for 500kg 800kg 1000kg

FOB Price

Negotiable / Square Meter

1 Square Meter(Min.Order)

Supply Ability 0 Square Meter / Square Meters per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	SHENXI		Place of Origin	China
Model Number	ZLP500-800

Product Description

Delivery Time:15 working days
Certification:CE,SGS

Pin Aluminum Suspended Working Platform Hanging Scaffold for 500kg 800kg 1000kg

Descrition:

Special Suspended Platform, also called Special Temporary Access Equipment, is a mobile modular gantry specially designed to meet specific tasks and requirements.

These include: U Type Suspended Platform, Exterior Suspended Platform, Pin-style Platfrom, Moveable End Stirrup Platform, Circle Platform, Gondola, Suspended Chair, Chimney Suspended Platform, and Double Deck Platform.

Key Features of Special Suspended Platform/ Gondola

–made of rigid aluminum or steel

–suitable for multiple uses

–powered by motor system

–adaptability and practicability

Main Applications of Special Suspended Platform/ Gondola

–construction and maintenance work for the building of various profiles

–used for cleaning, decorating, coating on the exterior walls of high buildings

–ideal for construction work in the difficult to access areas, such as chimney,

boiler, barn and pit, etc.

Specifications:

Type			ZLP500	ZLP630	ZLP800	ZLP1000
Rated Capacity			500kg	630kg	800kg	1000kg
Rated Lifting Speed			9-11m/min	9-11m/min	8-10m/min	8-10m/min
Wire Rope Diameter			8.3mm	8.3mm	8.6mm	8.6mm
Hoist	Type		LTD5	LTD6.3	LTD8	LTD10
	Rated Lifting Force		4.9kN	6.17kN	7.84kN	9.8kN
	Motor	Power	1.1kW×2	1.5kW×2	2.2kW×2	3.0kW×2
		Voltage	380V	380V	380V	380V
		Frequency	50Hz	50Hz	50Hz	50Hz
		Rotation Speed	1420rpm	1420rpm	1420rpm	1420rpm
		Brake Torque	15Nm	15Nm	30Nm	30Nm
Safety Lock	Type		LSB30II	LSB30II	LSB30II	LSB30II
	Permission Force of Impact		30kN	30kN	30kN	30kN
	Locking Cable Distance		＜100mm	＜100mm	＜100mm	＜100mm
Platform Size(mm)
