Middle Chrome 48 - 58HRC Cast Iron Forged Steel Grinding Balls Ak.= 3-12J / CM2 Minimum
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Low Chrome Hardness 48HRC Quenching Cast Iron Forged Steel Grinding Balls / S: 0.08Max
-
Impact Fatigue Life Test Ak. = 5 - 13J / CM2 Minimum Forged Steel Grinding Balls
-
Alloy Steel Forged Round Bar / Diameter 130mm - 700mm / UT Sep 1921 Class C/c
-
UT Sep 1921 Class C / c Carbon Steel Forged Round Bar / Process EAF + LF + VD + Q + T
-
Forged Round Bar for Cutting Tools, Casting Dies, Injection Moulds / Diameter 130mm, 700mm
-
Standard EN10083 / GB 3077 / ASTM 29 Alloy Steel Forged Round Bar Tolerance 0 / + 5mm
Product Details
| Brand Name | kyforging | Place of Origin | China | |
Product Description
Certification:ISO
Middle Chrome? 48 - 58HRC Cast Iron Forged Steel Grinding Balls Ak.= 3-12?J / CM2 ?Minimum
Specification:
|
Name |
Chemical Elements |
Impact fatigue life test |
Hardness |
|
High? Chrome? grind balls |
C:2.0~3.0;??? Si:0.8-1.6;???? Mn:0.60-2.0;? Cr:12-16;?? Mo:0.2-0.6;??? Cu: 1 max;? .?? P:0.08Max, ?? S:0.06Max; |
Ak.=5-13?J/CM2?Minimum |
56-62HRC |
|
Middle? Chrome? grind balls? |
C:2.0~3.4??? Si:0.8-2.2;? Mn:0.50-2.0;? Cr:5-8;?????? Mo:0.1max? Cu:0.8max;? P:0.08Max, ???? S:0.06Max; |
?Ak.=3-12?J/CM2?Minimum |
?48-58HRC |
|
Low? Chrome? grind balls |
C:2.6~3.20?? Si:0.8-1.6;?? Mn:0.60-1.50;? Cr:0.50-3;?? Cu:0.8max;?? .P:0.10 Max, ??? S:0.08Max; |
?Ak.=5-8? J/CM2? Minimum |
?≥48HRC |
The process line of production
RAW MATERIALS → CUTTING → STOVE → AUTOMATIC PRODUCTION-LINE → TRANSFER MACHINE → QUENCHING → HEAT TREATMENT → DIMENSION TESE →PACKING →TRANSPORTATION OR SEA FREIGHT
Cast iron grinding ball with better casting propertyand damping performanceis often used in the shaft of complex outside structure.Especially is rare-earth , and is applied to automobile, diesel engineer, Ore powder extract, Cement plants, et c.
Applications:
a) Mining
b) Cement plants
c) Power stations
d) Chemical industry and machinery
