low price stone cnc engraving equipment

FOB Price

Negotiable / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	China
Model Number	PC-9015SS

Feature:

1. Whole machine is welded with seamless steel structure,the stability is excellent, not easy to be deformed.

2. China 3KW constant power rate spindle(special for stone and metals).

3. The machine adopts gantry movement,it can process any kinds of materials freely.

4. Three axes adopt imported ball screw ,stable working,high precision and long life time.

5. X ,Z axes are dustproof.It makes sure the steady working performance of the machine for long-term using.

6. Well compatibility:CAD/CAM designing software e.g.

Type3/Artcam/Castmate/Wentai etc.

7. Has the function of forecasting process time.

8. Adopt imported linear square orbit,highprecision,heavy loading and long lifetime.

9. The machine has water tank and automatic water cooling system.

10. High precision,the curving and linear speeds are consistent.Adopting execellent parts makes the fault rate to be the lowest one.

Technical Parameter:

Model	PC-9015SS	PC-1318SS	It can be customized
X.Y working area(mm)	900*1500	1300*1800
Z working area	120mm
Resolution	0.01mm
X,Y structure	Imported ball screw
Z structure	Imported ball screw
Max speed	12m/min
Spindle power	3KW (constant power rate spindle)
Spindle rotating speed	0-24000r/min
Cooling mode	Water cooling
Working voltage	AC220V/50/60 Hz ,2PH(AC380V/50/60 Hz ,3PH)
Drive Motor	Stepper
Command	G code.u00.mmg*plt
Operating system	DSP/NC Studio
Diameter of cutter	3.175-8
Work-holding	By clamp

Applicable Industries:

Stone working :engraving various granite,bluestone,marble,gritstone,soapston and etc.

Metal processing industry.

Applicable Materials:

All kinds of stone,metal,wood,glass,pvc,plastic,etc.
