220V AC / 50Hz / 60Hz HR-150DT Rockwell Hardness Tester Dial Display HRC / HRB Scales

220V AC / 50Hz / 60Hz HR-150DT Rockwell Hardness Tester Dial Display HRC / HRB Scales

The HR-150DT Rockwell hardness tester, appreciated for its accuracy and easy operation, works entirely

conform the international Rockwell standard. Depending on the combination of indenter type and applied total

test force, a unique symbol is given to each Rockwell scale. The HR-150DT features both specific Rockwell

scale HRC and HRB on a dial. The appropriate force should be adjusted manually, using the dial on the right

side of the machine. After application of the preliminary force, the HR-150DT will proceed with a full automatic

test: loading, duration, unloading, and will display the hardness directly

Details:
Applications:
Cemented carbide
Thin steel plates
Case hardened steel
Copper
Bearing metal
Annealed steel
Brass
Hard-drawn aluminum alloys
Beryllium copper
Phosphor bronz
Specifications:
Preliminary test force (minor load): 98.07N(10kgf)
Test force (test load): 588.4N (60kgf), 980.7N (100kgf), 1471N (150kgf)
Table up/down drive: Manual
Load application: Automatic (loading-duration-release)
Load duration: 0s to 30s (specified in 1s increments)
Display: Dial
Hardness scales: HRC, HRB
Hardness increment: 0.1 (for each scale)
Maximum height: 170mm (6.7")
Maximum depth: 165mm (6.5") from center of indenter shaft
Power supply: 220 V AC/50/60Hz
Dimensions (WxDxH): 215x500x750mm (8.46x19.68x29.53")
Mass: 85kg
?
