CNC Video Measuring Machine
Negotiable
/ Piece
1 Piece(Min.Order)
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | Leader | Place of Origin | China | |
| Model Number | CNC type |
Product Description
Features:
• X,Y and Z axis are controlled with step servo, with high positioning accuracy and smooth movement
• Joystick and mouse operation, easy to use
• High-hardness, high-precision and non-deformable granite base and upright columns are stable, durable and elegant
• Programmable LED cold lights adopted for surface lamps can carry out surface measurement for various complicated work-pieces, with higher measurement accuracy
• Standard with automatic software can measure the complex work-pieces with high efficiency
• Fast Auto Focus, user can choose auto zoom as option according to the needs
Parameter:
|
Model
|
SV 250
|
SV 300
|
SV 400
|
|
|
Stage Size (mm)
|
450 x280
|
500 x 300
|
606 x 466
|
|
|
Glass Size (mm)
|
306*196
|
350 x 280
|
450 x 350
|
|
|
Travel (mm)
|
X axis
|
220
|
270
|
370
|
|
Y axis
|
120
|
170
|
270
|
|
|
Z axis
|
150 (for focus)
|
150 (for focus)
|
150 (for focus)
|
|
|
Driving System
|
Servo Motor Control
|
|||
|
Speed
|
200 mm/s
|
|||
|
Resolution of X/Y/Z-axis
|
0.0005 mm (0.5μm)
|
|||
|
Positioning Accuracy
|
0.001 mm (1 μm)
|
|||
|
Accuracy
|
≦3.0 + L/75 (μm)
|
|||
|
Software
|
Quick Image Measuring software QIM-5008 & USB
|
|||
|
Video System
|
• CCD Camera: Japan SONY Color 1/2“ CCD Camera
• Lightening System: Cold-light source Surface and Transmission illumination • Zoom Lens: U.S.A Navitar Zoom Lens • Magnification of field lens: 0.7X-4.5X • Total Magnifications: 30X-190X • Object View: 10.6mm-1.6mm |
|||
|
Weight (KG)
|
145
|
170
|
270
|
|
|
Power Supply
|
AC220V/110V 50/60 Hz
|
|||
