optical probe for smart meter communication

Brand Name	Telink		Place of Origin	China
Model Number	TL-OPUSB-IEC

The optical probe TL-OPUSB-IEC for smart metering is an interface for data exchange between a consumption meter (eg, electric meter, gas meter, heating meter, water meter, etc.) and a peripheral device via infrared optical waves. The optical reading head is manufactured in accordance with the standard IEC 62056-21 (IEC 1107) . Our optical probe TL-OPUSB-IEC has on one end an usb type A connector which can be connected to your peripheral device that supports USB-Host. There is a fix mounted magnetic ring on the other end of the optical reading head TL-OPUSB-IEC, which will be docked on your consumption counter. Please note that additional, specific software is necessary to exchange data between the consumption meter and your peripheral device. Mechanical description of the optical probe TL-OPUSB-IEC: Dimensions (Diameter x H): 32 x 27 mm Magnetical holding force: > 15 N Casing material : ABS Cable length: 2.0m OR 1.2m Weight: approx. 85gr color:blue Electronical description of the optical probe TL-OPUSB-IEC: Standard: IEC 62056-21 (IEC 1107) Power consumption: <100mA (communication process) Operating voltage: 5V passive (from the USB interface) Data baud rate: 19200 bit / s Electrical interface: USB 2.0 Wavelength: 880nm
