540TV Lines Waterproof Infrared Camera with 20 M IR Series Distance

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	VEACAM		Place of Origin	China
Model Number	VC20E

Delivery Time:3-10 Days,Depends on Quantity
Certification:CE,FCC,RoHS

540TV Lines Waterproof Infrared Camera with 20 M IR Series Distance

Features:
Waterproof?IR?Camera
LED:￠5X23PCS, 20MIRRange
3.6mm?Len, IP66?Rating
?

Specification:

Moddel	VC20E7	VC20E5	VC20E4	VC20E1
Image Sensor	1/3' SONY CCD	1/3' SONY CCD	1/3' SONY CCD	1/4' SHARP CCD
Horizontal Resolution	540TV Lines????? Low Illumination	480TV Lines	420TV Lines
Pixels	?????????????????????? ?? ?PAL:752(H)×582(V), ????????????? NTSC:768(H)×494(V)		????????????????????? ? ? PAL:500(H)×582(V)?????????????? ????? NTSC:510(H)×492(V)
TV System	PAL/NTSC
IR LED	￠5X23 PCS
IR Series Distance	20 M
Lens	3.6mm Len
Sync System	Internal
IR Status	Under 10 Lux By CDS
Usable Illumination	0.001Lux/F2.0	0.0005Lux/F2.0		0.01Lux/F2.0
IR Power On
S/N Ratio	≥54dB (AGC OFF)	≥48dB (AGC OFF)
Gamma Correction	0.45
Video Out	Composite Signal (1.0Vp-p, 75Ω)
Scanning System	PAL:625 Lines, 50 Field/Sec;NTSC:525 Lines, 60 Field/Sec
Electronic Shutter Time	Auto:PAL 1/50-1/100, 000Sec;NTSC 1/60-1/100, 000Sec
Operation? Temperature	-10℃ ~ +50℃ RH95% Max
Storage? Temperature	-20℃ ~ +60℃ RH95% Max
White Balance	Auto
Power Source	DC12V 750mA
Dimension	69(W)x65(H)x170(D)mm
Weight	??????????????????????????????????? 750g
