1 Ton Electric Chain Hoist EHA Type for Heavy Duty Industry

Brand Name	Shuangpeng		Place of Origin	China
Model Number	EHA

Delivery Time:Based on client's needs
Certification:ISO9001:2008

1 Ton Electric Chain Hoist EHA Type for Heavy Duty Industry

Lifting capacity	0.5~20ton
Lifting Height	6~18m
Lifting Speed	2.5/10 m/min

The Electric Chain Hoist (ECH) series was designed for heavy duty industrial applications, which greatly reduce down time and operational costs.? Nante chain hoists tolerate large loads with ease and require little maintenance.? They provide more allowance for side pulling, and provide true vertical lift at no extra cost.

EH three phase electric chain hoists are equipped with the latest technology in the market today. All models include a low headroom, lightweight body with a fan-cooled motor, standard thermal motor protection and a count hour meter for preventive maintenance. Simply the best hoists on the market!

Whether chain hoist or wire rope hoist, electric or pneumatic; our line of powered hoists are ideal in manufacturing, power generation, and industrial facilities where heavy items are lifted and positioned as part of production or warehousing. Our new model high-capacity wire rope hoist complements our line with capacities up to 50 Tons. We offer a full line of manual hoists, both hand chain and lever tools, which are used primarily for maintenance and construction activities.

With suspension hook. push, geared or electric trolley. Standard lift height 3 m, control cable 2.5m Operating voltage 220-440V, 50/60Hz, 1-3 phase Low voltage control 36V is standard. High efficient energy-saving motor, asbestos free brake system. Light weight, compact and solid body case. Top and bottom hooks are fitted with safety latches as standard. Drop forged steel suspension & load hooks are heat treated and fracture resistant. In case of dangerous overloading or abuse, the hook does not fracture but will slowly yield. Solid chain bucket. Super strong surface hardened chain Limit switch devices fitted at both top & bottom ends, switch off power automatically to prevent load chain from running out. Phase error relay, a specially designed current-post, prevents motor from running at incorrect wire connection.

General Drawing or Sketch or Draft Drawing

MODEL		EHA-005	EHA-010	EHA-020	EHA-030
CAPACITY? (TON)		0.5	1.0	2.0	3.0
STANDARD LIFT? ( M)		3	3	3	3
PROOF LOAD? (Kn)		6.3	12.5	25	37.5
MOTOR POWER? (KW)		0.8	1.1	1.1	1.1
Group ISO		M4	M4	M4	M4
NO. OF FALLS OF LOAD CHAIN		1	1	2	3
LOAD CHAIN DIA.?(MM)		7.1X21	7.1X21	7.1X21	7.1X21
LIFTING SPEED?( M/MIN.)		5.80	4.30	2.15	1.43
DIMENSIONS (MM)	A	150
