High Energy Density Rechargeable GSP052030 3.7V 200mAh Polymer Lithium Ion Battery

No.

Item

Rated?Performance

Remark

1

Rated?Capacity

Minimum

200mAh

Standard?discharge(0.2C?C5A)?

after?Standard?charge

2

Nominal?Voltage

3.7V

Mean?Operation?Voltage?

During?Standard?Discharge?

After??Standard??Charge

3

Voltage?at?end?of

Discharge

3.0V

Discharge?Cut-off?Voltage

4

Charging?Voltage

4.2±0.03V

5

AC??(1KHz)?Impedance

?New?Cell?Max.(mW)

≤150mΩ

6

Standard?charge

Constant?Current?0.5C5A

Constant?Voltage?4.2V

0.01?C5A?cut-off

Charge?time?:?Approx?4.0h

7

Standard?discharge

Constant?current?0.2?C5A

end?voltage?3.0?V

8

Fast?charge

Constant?Current?1C5A

Constant?Voltage?4.2V

0.01?C5A?cut-off

Charge?time?:?Approx?2.5h

9

Fast?discharge

Constant?current?1?C5A

end?voltage?3.0?V

10

Maximum?Continuous?

Charge?Current

1?C5A

11

Maximum?Continuous?

Discharge?Current

1.5?C5A

12

Operation?Temperature?Range

Charge:?0~45℃

60±25%R.H.

Be?Cell

Discharge:?-20~60℃

13

Storage?Temperature

Range

Less?than?1?year:?-20~25℃

60±25%R.H.

at?the?shipment?state

less?than?3?months:?-20~40℃

14

Weight

Approx?:11g

Bare?Cell

15

Cell??Dimension

Length:?Max.30mm

Initial??Dimension

Width:?Max.20mm
