High Resolution P10 RGB Stadium Basketball Led Perimeter Board Advertising

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	S&B		Place of Origin	China
Model Number	SBO-P10

Delivery Time:10~20 days
Certification:CE, RoHS, CCC

High Resolution P10 RGB Stadium Basketball Led Perimeter Board Advertising

2011 Asian cup LED supplier

1. CE&RoHS certificate

2. 24 months warranty and Life long free tech-support

3.Excellent contrast ratio, high resolution/high definition

4.Perect uniformity and no mosaic

5. Waterproof IP65

6. Light weight and easy to install

7. Available models: P10, 12, 16, 20, 25, 31.25, ect.

Application:

It is widely used all kinds of Stadium.

Advantage:

1. High Contrast ratio: 4000:1

2. First-class LED chip

3. Clear vivid image quality

4. Long life time

5. Easy Installation & Operation

6. Convenient Servicing

SBO-P10 (Pitch 10mm outdoor full color-1/4 scan)
Colour temperature	5000~9000 k
Pixel structure	φ3 oval lamp, 1R1G1B
Pixel pitch	10mm
Pixel density	10, 000 dots/㎡
Luminance	7, 500cd/㎡
Module dimension	160mm(W) * 160mm(H)
Module resolution	16 pixel(W) * 16 pixel mm(H)
Cabinet dimension	1280 * 960mm
Cabinet resolution	128 * 96
Cabinet area	1.229 sq. meter
Optimal visual distance	>10m
Visual angel	110 / 50 degree (H/V)
Max power consumption	≤1200w / ㎡
Average power consumption	≤750w / ㎡
Brightness adjustment	Adjust according to the environment
Brightness adjustment	brightness software (0%-100%adjustable)
Gray scale	point by point 4096 gray grade levels of
Gray scale	each color, 16 bits γ correction available
Drive mode	1/4 dynamic scan, constant current
Frame frequency	≥60HZ
Refresh frequency	≥480HZ
Input voltage	AC 90~260 volts
Operation temperature	﹣40℃~ +65℃
Operation humidity	10％～90％
Input signal	S-video, RF, RGB, Yuv, YC, composite…
Control system	DVI card + master control card + receiver card
MTBF	>5000 hrs
Life span (50% brightness)	100, 000 hrs
Malfunction dot rate	1/10000
Ingress protection rate (Front/ rear)	IP65 / IP54
Cabinet material	Epoxy paint coated, aluminum / iron
Application:	Rental / Permanent installation available
