RGB P12 Outdoor Basketball LED Pperimeter Advertising Display IP65

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	S&B		Place of Origin	China
Model Number	SBO-P12

Delivery Time:10~20 days
Certification:CE,RoHS，CCC

RGB P12 Outdoor Basketball LED Pperimeter Advertising Display IP65

2011 Asian cup LED supplier

1. CE&RoHS certificate

2. 24 months warranty and Life long free tech-support

3.Excellent contrast ratio, high resolution/high definition

4.Perect uniformity and no mosaic

5. Waterproof IP65

6. Light weight and easy to install

7. Available models: P10, 12, 16, 20, 25, 31.25, ect.

Application: It is widely used all kinds of Stadium.

Advantage:

1. High Contrast ratio: 4000:1

2. First-class LED chip

3. Clear vivid image quality

4. Long life time

5. Easy Installation & Operation

6. Convenient Servicing

SBO-P12 (Pitch 12mm outdoor full color-1/2 scan)
Colour temperature	5000~9000 k
Pixel structure	φ3 oval lamp, 2R1G1B
Pixel pitch	12mm
Pixel density	6, 944 dots/㎡
Luminance	7, 000cd/㎡
Module dimension	192mm(W) * 192mm(H)
Module resolution	16 pixel(W) * 16 pixel mm(H)
Cabinet dimension	1152 * 768mm
Cabinet resolution	96 * 64
Cabinet area	0.885 sq. meter
Optimal visual distance	>12m
Visual angel	110 / 50 degree (H/V)
Max power consumption	≤1100w / ㎡
Average power consumption	≤700w / ㎡
Brightness adjustment	Adjust according to the environment
Brightness adjustment	brightness software (0%-100%adjustable)
Gray scale	point by point 4096 gray grade levels of
Gray scale	each color, 16 bits γ correction available
Drive mode	1/2 dynamic scan, constant current
Frame frequency	≥60HZ
Refresh frequency	≥480HZ
Input voltage	AC 90~260 volts
Operation temperature	﹣40℃~ +65℃
Operation humidity	10％～90％
Input signal	S-video, RF, RGB, Yuv, YC, composite…
Control system	DVI card + master control card + receiver card
MTBF	>5000 hrs
Life span (50% brightness)	100, 000 hrs
Malfunction dot rate	1/10000
Ingress protection rate (Front/ rear)	IP65 / IP54
Cabinet material	Epoxy paint coated, aluminum / iron
Application:	Rental / Permanent installation available
