HT2600 Programmable DC power supply, 24-bit A/D converter, triple outputs

FOB Price

USD $1400 - $2100 / Piece

2 Pieces(Min.Order)

Supply Ability 0 Piece / Pieces per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	HENKI		Place of Origin	China
Model Number	HT2600

Product Description

The HT2600 product line, which includes HT2620, HT2630, HT2631, HT2632, HT2636 and HT2664, is a programmable DC power supply family that features high accuracy, high stability and low noise with independently operative 3 channel outputs.

With the embedded16-Bit digital to analog converter, which controls output voltage/current, and 24-Bit analog to digital converter, which reads output voltage/ current and high accuracy voltage reference resources, users attain precise input and output figures. The HT2600 also achieves higher accuracy by its software calibration, which avoids errors caused by manual operations.

In terms of over voltage/current protection (OVP/OCP), the HT2600 rapidly detects a problem by utilizing a combination of software configuration and hardware detection, which ensures connected objects against damages if any problem occurs.

1.2 Features
1. Individual operative design of 3-channel output terminals
2. Stable output regulation with low noise and high precision
3. High resolution of output/Read capabilities:
Voltage= 1 mV. Current= 100uA.
4. Remote Sense compensation
5. Front panel and rear panel output terminals
6. Back lighted 160x160 LCD display
7. Over-voltage, over-current and over-temperature protection
8. Short circuit and reverse polarity Protection
9. Intelligent Fan control
10. Auto Run mode and delay time setting functions
11. Parallel Connection , Series Connection and track modes
12. 100 configurable and recallable states in the memory
13. Output ON/OFF delay time function
14. ON/OFF control at the output terminals
15. Standard RS-232C and USB interfaces
16. Optional GPIB(IEEE-488.2) interface

Specifications:

Model		HT2620	HT2630	HT2631	HT2632	HT2636	HT2664
CH1&CH2 Output Rating:
	Voltage	0 ~ 20V	0 ~ 32V	0 ~ 32V	0 ~ 32V	0 ~ 36V	0 ~ 64V
	Current	0 ~ 3A	0 ~ 1.2A	0 ~ 2A	0 ~ 3A	0 ~ 1.5A	0 ~ 1A
	OVP	0.1 ~ 21V	0.1 ~ 34V	0.1 ~ 34V	0.1 ~ 34V	0.1 ~ 38V	0.1 ~ 66V
	OCP	0.01 ~ 3.2A	0.01 ~ 1.4A	0.01 ~ 2.2A	0.01 ~ 3.2A	0.01 ~ 1.7A	0.01 ~ 1.2A
CH3 Output Rating:
	Voltage	0 ~ 6V	0 ~ 32V	0 ~ 6V	0 ~ 6V	0 ~ 6V	0 ~ 6V
	Current	0 ~ 5A	0 ~ 1.2A	0 ~ 5A	0 ~ 3A	0 ~ 3A	0 ~ 3A
	OVP	0.1 ~ 7V	0.1 ~ 34V	0.1 ~ 7V	0.1 ~ 7V	0.1 ~ 7V	0.1 ~ 7V
	OCP	0.01 ~ 5.2A	0.01 ~ 1.4A	0.01 ~ 5.2A	0.01 ~ 3.2A	0.01 ~ 3.2A	0.01 ~ 3.2A
Load Effect
	Voltage	≦0.01% + 2mV
	Current	≦0.06% + 2mA
Source Effect
	Voltage	≦3mV
	Current	≦3mA
Ripple and noise
	Voltage	≦1mVrms
	Current	≦3mArms (≦5mArms@Load>3A)
Programming accuracy
	Voltage	≦0.02% + 5mV
	Current	≦0.05% + 8mA
	OVP	≦0.05% + 20mV
	OCP	≦0.1% + 5mA ( +10mA@Load>3A)
Programming Resolution
	Voltage	1mV
	Current	100μA
	OVP	10mV
	OCP	1mA
Readback accuracy
	Voltage	≦0.02% + 5mV
	Current	≦0.02% + 5mA
Readback Resolution
	Voltage	1mV
	Current	100μA
Transient Response Time		≦50us (50% to 100% load effect)
OVP/OCP Accuracy
	Voltage	≦0.05% + 20mV
	Current	≦0.1% + 5mA ( +10mA@Load>3A)
Stability (8hrs)
	Voltage	≦0.02% + 2mV
	Current	≦0.1% + 1mA
Temperature Coefficient (per ℃)
	Voltage	≦0.01% + 2mV
	Current	≦0.02% + 3mA
Remote Sense Compensation		1V
Response Time
	Voltage Up	10% ~ 90% ≦100ms
	Voltage down	90% ~ 10% ≦100ms with ≧10% rating load
Track Mode
	Tracking Error	≦0.02% + 20mV
	Series Load Effect	≦20mV
Parallel Connection
	Program Accuracy	Voltage: ≦0.05% + 10mV, Current: ≦0.1% + 10mA
	Load Effect	Voltage: ≦0.01% + 2mV, Current: ≦0.06% + 2mA
	Source Effect	Voltage: ≦3mV, Current: ≦6mA
Storage Memory
	Store/Recall	0 ~ 99, 100 configurable settings
Timer
	Setting range	0.1 ~ 9999.99sec
	Resolution	0.01sec
	Function	Auto Run mode
Trigger Delay
	Setting range	0 ~ 10.00sec
Interface
	Standard	RS-232C, USB
	Optional	GPIB
AC Input Voltage Ranges		AC 100/120/220V ±10%, 230V(+10%, -6%), 50/60Hz
Operating Environment		10℃~35℃ for full rated output; maximum range: temperature 0℃~ 40℃, humidity:<85%RH
Storage Environment		Temperature: -10℃~70℃, Humidity:<70%RH
Dimensions		213(W) x 132(H) x 400(D)
Weight		Approximately 10KG
Accessories		User’s guide x1, power cord x1, test lead x3
Warranty		1 Year
