5V1mA button battery test instrument

5V1mA button battery test instrument

Features

1,Channels

Eight independent programmable channels.

Each channel can set different working modes and works independently.

2,Programs

The software (TC5.3) with calibration software can set various working modes for measuring capacity and cycle life of all types of rechargeable battery cells.

Working modes Include constant current discharge, constant current charge, constant voltage charge, rest, as well as voltage, current, time, capability, negative voltage slope, and other limit conditions.

The calibration software can easily calibrate the analyzer and revise the case number.

3,User-friendly software

With real-time monitoring windows and integrated graph/data windows, the testing process can be observed more directly and efficiently. During the test, the software will give timely instructions and warnings, provide intelligent help both in English and Chinese.

4,Test reports and curves for analysis

Different types of curves can be created by software base on use defines. (Voltage-time curve, current-time curve, capacity-voltage curve, loops times-charge/discharge capacity curve, loop times-charge/ discharge efficiency curve, etc.

Forms of curves are created by software. User can easily compare the performance of the batteries tested in channels both visually and statistically.

Complete record of all the events happened in the test. By checking the record, user will easily find these external interferential causes.

5,Protection and auto-recover

If power failure occurs during testing, the system will shutdown running channels and, once power recovers, will automatically resume those stopped channels and ensure that the test is normally conducted and the date will never lose any cases.

6,Battery Holder

The tester provides two types of battery holders.  8 alligator clips with cable and 8 spring load holders with adjustable length are competent to measure flat or cylinder battery.

Measure cylinder cell up to from 10 to 70 mm height which is adjustable

Measure any cell by flat clips. 8 cables with flip clips are included

Measure coin cells with diam. upto 25mm by 8 channels coin cell testing board (optional)

7,Precision current

 The system provides measure accuracy reach up to 0.1 % of full scale .

Systems can be easily customized with voltages up to 800 VDC and currents ranging from 1mA to 1000 Amps. If you do not see something that meets your needs, contact us with your requirements. There is a good chance we can build it.
