Home > Products > Slitting line > Metal coil Slitting Line
Metal coil Slitting Line
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Place of Origin | China | |
| Model Number | 350--2200 |
Product Description
|
Slitting Line |
||||
|
Application |
To slit wide steel coil to strips and rewind them back to coils |
|||
|
Materials |
SPCC, SPHC, GI, SUS, TP, TFS, Aluminum, etc |
|||
|
Main Structure |
Storage saddle/coil turner/coil car/uncoiler/leveler/looping pit table/side guide/pinch roll/slitter/scrap winder/looping pit table/separation section/tension section/recoiler/hydraulic shear/exit coil car/ hydraulic support |
|||
|
Model |
ZC-650 |
ZC-1250 |
ZC-1600 |
ZC-1850 |
|
Max Coil Width |
700mm |
1300mm |
1650mm |
1850mm |
|
Slitting Thickness Range |
0.2-2.0mm |
0.3-3.0mm |
0.3-3.0mm |
0.3-3.0mm |
|
Max Uncoiling Weight |
5T |
15T |
20T |
25T |
|
Max Recoiling Weight |
5T |
15T |
20T |
25T |
|
Slitting Line Speed |
150 - 200m/min |
150 - 200m/min |
150 - 200m/min |
150 - 200m/min |
|
Original Coil I.D. Range |
385-520mm |
385-520mm |
385-520mm |
385-520mm |
|
Slitting Capacity |
30 Strips |
30 Strips |
30 Strips |
30 Strips |
|
Strip Width |
≥20mm |
≥20mm |
≥20mm |
≥20mm |
|
Recoiler I.D. |
508mm |
508mm |
508mm |
508mm |
|
Slitting Width Tolerance |
≤±0.05mm |
≤±0.05mm |
≤±0.05mm |
≤±0.05mm |
|
Burrs |
≤±0.02mm |
≤±0.02mm |
≤±0.02mm |
≤±0.02mm |
|
Speed Regulation |
DC, frequency control |
DC, frequency control |
DC, frequency control |
DC, frequency control |
