CMOS MINI Camera SC-1001CAR
Negotiable
/ Piece
1 Piece(Min.Order)
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | OEM&safecameras | Place of Origin | China | |
| Model Number | SC-1001CAR |
Product Description
Certification:CE,FCC,ROHS
Feature
380 TV Lines for clear image resolution Light weight & tiny for discreet daytime surveillance Easy mounting for indoor use 16ft (5m) RCA AV cable Plugs into any DVR, VCR, TV or Swann security monitor Metal Case? IR night view 3-5meters| MODEL： | SC-1001CAR |
| Image Sensor： | 1/3 OV7959 Cmos |
| System： | PAL/NTSC |
| Pixels： | PAL:628(H)X582(V);NTSC:510(H)X492(V) |
| Horizontal Resolution： | 380-420TVL |
| Minimum Iumination： | 0.5lux(F1.2, IR OFF) |
| Lens： | 52°(f=6mm);72°(f=3.6mm) |
| White Balance： | Auto |
| Gaia Conrtol： | Auto |
Specification
|
? Item
|
Value
|
|
|
?TV System
|
? PAL
|
? NTSC
|
|
?Validity Pixel
|
?628(H) x 582(V)
|
? 510(H) x 492(V)
|
|
?Image Device
|
? 1/3" OV7959 CMOS
|
|
|
?Horizontal Definition
|
? 380-420TV Line
|
|
|
?Angular Field of View
|
? 52°(f=6mm);72°(f=3.6mm)
|
|
|
?Minimum Illumination
|
? 0.5Lux/F1.2
|
|
|
?Scanning Frequency(H)
|
? 15.625KHz
|
? 15.734KHz
|
|
?Scanning Frequency(V)
|
? 50Hz
|
? 60Hz
|
| ?Night View Distance | ? 3-5Meters | |
|
?Power Adapter
|
? DC12V IR Off (30mA) IR On(60mA)
|
|
|
?Dimension
|
? 48x39x65mm
|
|
|
?Weight
|
?30g
|
|
| ? Packaging Dimension | ?50x42x70mm | |
|
?Video Output
|
?1Vp-p@75Ω, S/N>38dB
|
|
|
?Audio Output
|
?1Vp-p@600Ω
|
|
| ?AGC | ?Auto | |
| ?Operation Temperature | ?-10~50/+14~+122°C/°F | |
| ?Operating Humidity | ?85%RH | |
| ?Syncronization System | ?Internal | |
| ?Backlight Compensation | ?Auto | |
| ?Electronic Shutter | ?1/50(1/60)~1/100, 000sec | |
| ?White Balance | ?Auto | |
| ?S/N Ratio | ?>48db | |
| ?Gamma Correction | ?>0.45 | |
