Home > Products > Core Drill Rig > FDP-32 HYDRAULIC DIRECTONALDRILLING RIG
FDP-32 HYDRAULIC DIRECTONALDRILLING RIG
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | SINOCOREDRILL | Place of Origin | China | |
Product Description
Certification:CE
The whole car-mounted integrated equipment of rubber track, adopt the domestic famous-brand Deutz turbo-charged diesel engine, motive force is powerful. Motor - chain feed mechanism, Driller can use two hydraulic clamps for the making up and breaking away of drilling rods easily. Easy operation of all hydraulic drives and central control from the Control Panel. Pairs of hydraulic power wrench device and function console. High drilling rate , reliable functions, high efficiency to work. Mud mixing system with 2m3 tank has high efficiency to mix.
SPECIFICATIONS
|
Max?push?capacity |
320KN |
|
Max?pull?capacity |
320KN |
|
Rated?torque |
13000?N.M |
|
Rated?speed |
Lower?0-50r/min |
|
High?0-100r/min |
|
|
Feed?travel |
3300?mm |
|
Drilling?angle |
10-20° |
|
Length?of?pull?backward |
500?m |
|
Diameter?of?guide?hole? |
130?mm |
|
Max?diameter?of?reaming |
1000?mm |
|
Pressure?of?hydraulic?system? |
20MPa |
|
Power?of?drill?(diesel?engine) |
145kw |
|
Weight? |
8400?kg |
|
Dimensions?(L×W×H) |
5820×2250×2400?mm |
|
Move?mode |
Moves?with?track |
|
Mud?pump?Model |
BW-250 |
|
Mud?pump?Flux |
250?L/min |
|
Drill?pipe |
Φ73mm×3000mm |
