CCTV Mini Camera Built-in Pre-Amp Audio

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	China
Model Number	GT-M200

Model Number	GT-M200
Effective Pixels	NTSC:537(H) x 505(V) PAL:537(H) x 597(V)
Electronic Shutter	1/50-1/120,000sec
Image Sensor	1/3" Sony Super HAD II CCD
Horizontal Resolution	420 TV lines
Minimum Illumination	0 Lux / F1.2 IR on
S/N ratio	48dB(AGC OFF)
Gain Control	AGC
White Balance	Auto
BLC	Auto
Gamma Correction	0.45
SYNC System	Internal
Lens	3.6mm Optional
Video Output	1.0 Vp-p, 75 Ohm
IR LED	12pcs 850nm infrared LED
IR Distance	12meters (Subject to IR reflection conditions )
IR Status	IR on: Under 10 Lux, by PT auto control
LED life	More than 10,000 Hours
Power Requirement (± 10%)	DC12V, 500mA
Power Consumption (± 10%)	IR on: 300mA, IR off: 120mA
Operation Temp.	Operating: -20 ~ + 55 ℃ , Storage: -30 ~ + 80 ℃
Dimensions ( mm )	85(W) x 55(H) x 85(L)
Weight ( N.W)	130g
